BOPP Film Lamination Machine

Supply Ability: 100 Set/Sets per Year
Shipping: 90 DAYS
Payment Terms: L/C, T/T
Place of Origin: Guangdong in China
Packaging Details: some in wooden cases packaging, another nude

Specifications

Having been exported to a few foreign countries and regions, film lamination machine,
is of good quality and reasonable price.

Lamination Machine is designed and developed by ourselves - is the first one in China.

This lamination machine adopts the construction of dual extruders and dual laminating rolls. It uses PP or PE as raw material, through the flow-casting method and film lamination technology, to accomplish double-sided lamination with substrates (such as plastic woven fabric, paper, etc. ) in one production flow. The line is especially suitable for using tubular woven sacks as the substrates, and producing double-sided coated tubular sacks or double-sided BOPP color-film laminated woven sacks.

Simple structure and easy to operate features this PP lamination machine. Compared with a single-extruder and single-die lamination line, the line can accomplish double-sided lamination with the substrate in one production flow, which improves production efficiency greatly, reduces energy consumption and labors, and guarantees their quality.

For double-sided color printed film lamination, there are two modes for your choose, you can seee as follow:

Manual Registration Mode: using magnetic powder to brake tension control, manually adjusting for color-film registration. It is characterized by simple structure, easy to operate, and convenient for adjustment.

Automatic Registration Mode: using color-mark photocell detection, automatically registering the detected signals and adjusting (to control the motors of nip rolls for film feeding), so as to achieve automatic registration for color films at both sides. It is characterized by accurate registration, good stability, and high automation, which is especially suitable for producing high-grade double-sided color-film laminated sacks.

Main Technical Parameters:

Model

Item

SJ65-FMS800B

manual registration

SJ65-FMS800C

auto registration

Lamination Widthmm

400-650

450-650

Lamination Thickness (mm)

0.015-0.08

0.015-0.08

Lamination Mechanical Speed (m/min)

20-120

20-100

Screw Dia. × L/D

Φ 65× 33

Φ 65× 33

Roller Lengthmm

800

800

Die Lengthmm

850

850

Max. Unwind & Rewind Diametermm

1200

1200

Total PowerkW

120

130

Air Flowm3/min

0.6

0.6

Water Supplym3/min

circular water ≤ 25

0.5

0.5

Total Weight (t)

approx. 20

approx. 22

Dimensionsm

L× W× H

9.6× 5.5× 2.5

14.5× 5.5× 2.5

The specifications and technical parameters are subject to change without prior notice.

If you are interested in our film lamination machine, please feel free to contact.
