Ningbo Bonny Hydraulics Transmission Co., Ltd.
China Manufacturer with main products: Hydraulic Motor, Hydraulic Winch, Final Drive, Track Drive, Travel Drive, Winch Drive, Swing Drive, Track Undercarriage |
Home
>Products Catalog > Planetary Gearbox > Replace Brevini EC ET EM EQ S SL Series Planetary Gearbox
Replace Brevini EC ET EM EQ S SL Series Planetary Gearbox
| Supply Ability: | 1,500 Set(s) per Month |
|---|---|
| Shipping: | 15-45 days |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Zhejiang in China |
| Packaging Details: | standard woden case |
Quick Details
- Output Speed: on request
- Output Torque: 1000-450000Nm
- Brand Name: cathy
- Material: Forging
- Standard or Nonstandard: on request
- Input Speed: 500-3000rpm
- Gearing Arrangement: Planetary
- Model Number: BL300 series planetary gearbox
- Type: planetary gearbox
- Interchanged with: Brevini planetary gearbox
Specifications
High quality planetary gearbox manufacturer from China
Bonfiglioli 300 planetary gearbox, Brevini ED, ET, EQ, EM,EC and EL series gearbox,
Interchangeable with Brevini ED, ET, EQ, EM, EC and EL series, Bonfiglioli 300 series and Dinamicoil RE, RA series on performance and connection
We are the manufacturer of planetary gearbox (hydraulic transmission, slewing drive, swing drive gearbox) from China. We have more than 20 years experience in designing and manufacturing various kinds of planetary gearbox on customer requirements. Our company is with ISO9001: 2008 Quality Management Certificate, we provide a one year warranty and whole life technical service.
the rotary gearbox/swing speed reducer we produce is with Output torque from 1000-450000N. M, Reduction ratios from3.3 to 5000. Replace Bonfiglioli, Brevini, RR, O&K, Tejin, NACHI, KYB, Fairfield or Sauer, according to specially demands and design.
as a trustworthy manufacturer and supplier, we have a dominating market sharein China, and we also enjoy an increasing market share worldwide.Our products have been exported to:
-Europe: UK, Austria,Netherlands, Germany, Sweden
-North America: USA, Canada
-South America: Brazil, Argentina
-Russia, Australia,Turkey, Southeast Asia, Middle East, India, Korea and othercountries in the world.
Overview
the installation and overall dimension of planetary gearboxes are strictly designed in accordance with Italy and American manufacturers, so they can be completely interchangeable with Brevini ED, ET, EQ, EM, EC and EL series, Bonfiglioli 300 series and Dinamicoil RE, RA series on performance and connection dimensions. They are the ideal product to replace those Italian products.
Torque Range 1000---1.100.000 Nm
Transmissible Mechanical Power up to 450 kW
Gear Ratios i=3, 4 -- 5.000
Gear Unit Versions
Right angle (with a spiral bevel gear set)
Output Configuration
Foot and flange mounted
Output shaft
Output Configuration
Foot and flange mounted
Output shaft
Solid with key, splined, splined hollow,
Hollow with shrink disc
Hollow with shrink disc
Input Configurations
Flanged axial piston hydraulic motors
Hydraulic orbit motors
IEC and Nema motor adaptors
Solid input shaft
Flanged axial piston hydraulic motors
Hydraulic orbit motors
IEC and Nema motor adaptors
Solid input shaft
Hydraulic Brake
Hydraulically released parking brake on request
Hydraulically released parking brake on request
Electric Brake DC and AC type
Replasce for Brevini planetary gearbox:
Brevini S300 S400 S600 S850 S1200 S1800 S2500 S3500
Replasce for Brevini planetary gearbox:
Brevini S300 S400 S600 S850 S1200 S1800 S2500 S3500
EM1010 DE2010 EC2010 ET3010 EC3010 EC4010
EC3020 EQ4020 EC4020 ED2030 ET3030 EC3030 EQ4030 EC4030
EM1045 ED2045 EC2045 ET3045 EC3045 EQ4045 EC4045
EM1046 ED2046 EC2046 ET3046 EC3046 EQ4046 EC4046
EM1065 ED2065 EC2065 ET3065 EC3065 EQ4065 EC4065
EC3090 EQ4090 EC4090 EM1150 ED2150 ET3150 EC3150
EQ4150 EC4150 EM1250 ED2250 EC2250 ET3250 EC3250
EQ4250 EC4250 ED2320 ET3320
Technical Parameters
EQ4150 EC4150 EM1250 ED2250 EC2250 ET3250 EC3250
EQ4250 EC4250 ED2320 ET3320
Technical Parameters
Type |
Rated torque
(Nm) |
Rated power
(Kw) |
Input speed
(Max rpm) |
Ratio range for Inline gear |
Ratio range for Right angle gear |
Ratio range for Combined withworm gear |
Design |
BL300 |
1000 |
20 |
3000 |
3.3-2700 |
7-800 |
400-9000 |
A |
BL301 |
1750 |
30 |
3000 |
3.3-2700 |
7-800 |
400-9000 |
A |
BL303 |
2500 |
40 |
3000 |
3.6-2900 |
9-900 |
400-9000 |
A |
BL305 |
5000 |
60 |
3000 |
3.6-2900 |
9-900 |
400-9000 |
A |
BL306 |
8500 |
75 |
2500 |
3.7-2900 |
9-900 |
400-9000 |
A |
BL307 |
12500 |
100 |
2500 |
3.4-2500 |
13-800 |
400-9000 |
A |
BL309 |
18500 |
130 |
2500 |
3.4-2500 |
13-800 |
400-9000 |
B |
BL310 |
25000 |
150 |
2000 |
3.8-2500 |
40-900 |
400-9000 |
B |
BL311 |
35000 |
180 |
2000 |
4-2200 |
18-800 |
400-9000 |
B |
BL313 |
50000 |
200 |
2000 |
4-2200 |
18-800 |
400-9000 |
B |
BL315 |
80000 |
250 |
1500 |
4-2000 |
70-900 |
400-9000 |
B |
BL316 |
105000 |
270 |
1500 |
4-2000 |
50-600 |
400-9000 |
B |
BL317 |
150000 |
300 |
1000 |
4-1900 |
70-900 |
400-3000 |
B |
BL318 |
200000 |
340 |
1000 |
4-1100 |
200-700 |
400-9000 |
B |
BL319 |
300000 |
380 |
500 |
4-1400 |
300-800 |
1000-9000 |
B |
BL321 |
450000 |
450 |
500 |
4-1100 |
300-800 |
1000-9000 |
B |
Meanwhile, we can also design and manufacture planetary gearbox according to your requirements.
