Yancheng Shibo Machinery Manufacturing Co., Ltd.
China Manufacturer with main products: Spiral tube former, Spiral tubeformer, HVAC duct machine, Spiral tube former machine, Spiral tube forming machine, Spiral duct forming... |
| Place of Origin: | Jiangsu in China |
|---|---|
| Packaging Details: | WOODEN PACKAGE |
Specifications
Features
1. Cross sea longitudinal seam and horizontal and vertical seam.
2. The speed of welding is quick and the efficiency of welding is high.
3. According to the clients' demand, set the function of continuous weld and pulse weld.
4. Equipped with a high reliability control box
5. The welding speed can be regulated continuously.
6. Suitable for the site for welding airproof vesse
5. The welding speed can be regulated continuously.
6. Suitable for the site for welding airproof vesse
Technology Data：
|
Item Type |
FN-35 |
FN-55 |
FN-75 |
FN-100 |
|
Rated input capacity |
35KVA |
55KVA |
75KVA |
100KVA |
|
Rated input voltage |
1-38V/50HZ |
1-380V/50HZ |
1-380V/50HZ |
3-380V/50HZ |
|
Rated load cycle |
50% |
50% |
50% |
50% |
|
Max.input capacity |
45KVA |
88KVA |
110KVA |
170KVA |
|
Max.short circuit current |
6200A |
11000A |
16000A |
26000A |
|
Max.pressure of electrode |
400KGF |
600KGF |
1000KGF |
1000KGF |
|
The flow of cooling water |
6L/min |
6L/min |
8L/min |
8L/min |
|
Arm length |
600mm |
600mm |
600mm |
600mm |
|
Electrode journey |
80mm |
80mm |
80mm |
80mm |
|
Speed of welding |
0.5-3m |
0.5-3m |
0.5-3m |
0.5-3m |
|
Weight |
220kg |
280kg |
350kg |
400kg |
