Yancheng Shibo Machinery Manufacturing Co., Ltd.
China Manufacturer with main products: Spiral tube former, Spiral tubeformer, HVAC duct machine, Spiral tube former machine, Spiral tube forming machine, Spiral duct forming... |
| Place of Origin: | Jiangsu in China |
|---|
Specifications
1 summarize
This kind Auto CNC asymmetrical 3-roller bending machine adopts Siemens PLC made by Germany. The system set up round shape, square shape, oval shape and taper shape on it in advance (see to following drawing), when you operating only choose the right shape which you want to product. And also the customer can be drawing other shape which they want to do after that put the process into the system. Characteristic of this kind machine: easy to use, convenient, fast and good results processing. At the same time, to ensure the machining quality and service life of machine we used the import product for numerical control system and Electrical components.
The machine has compact structure, beautiful appearance, and high strength advantages, well received by customers. The product roll with high-quality materials, 40Cr after quenching, crude, refined car, and grinding, hard chrome plated to ensure the quality of life and processing. Cast iron with ball bearings made by the finish, rigid.
Touch screen with Panasonic 7-inch color touch screen; PLC programmer using Japanese original products, servo motors, drives, using the German Rexroth products. All electric components are used Schneider and Fuji components, thus ensuring that the product life, but also to ensure the product electronically controlled part of the sensitivity, accuracy and reliability of action. To ensure product quality.
2 Main technical
|
Item |
data |
Remark |
|
Diameter of the upper roller |
φ72mm |
1Radix |
|
Diameter of the down roller |
φ72mm |
1Radix |
|
Diameter of side roller |
φ70mm |
1Radix |
|
Min.diameter of the bending |
φ80mm |
|
|
Max.machining length |
1300mm |
|
|
Max.machining thickness |
1.2mm |
|
|
Feeding servo motor |
1.5KW |
|
|
motor of the side roller |
0.55KW |
|
|
feeding speed |
2.5m～6m |
adjustable |
|
voltage |
380V±10% |
|
|
frequency |
50HZ |
|
|
Work environment temperature |
40℃～-10℃ |
|
|
relative humidty |
±60% |
|
