Specifications

controller specifications

item		specification	remark
command	language	Function Control Language(FCL)
command	speed	Sequence-control directive:0.1~0.65μs Fixed-point calculations:0.15~5.55μs Floating-point operations:0.25~2.3μs Simulations:17.5~21.5μs
Memory capacity		8M byte
in/out point	Digital quantity in/out	Total point:8704	Remote PIO:8192 Direct PIO:512
	Analog input and output	Total point:2176点	Remote PIO: 2048 Direct PIO: 128
	Pulse input	(include in the item of "digital input/output")
	Counter	128
	Holding relay	1024
	Differential relay	1024
PIO transmission (T-link:IPU-Ⅰ)		Transmission rate:500kbps Transmission distance:1km(electricity),1 km(light)	Total extension distance:17 km
PIO transmission (Ethernet:IPU-Ⅱ)		Transmission rate:10Mbps Transmission distance:185m(electricity:coaxial cable)	Ethernet standard
Controller transfer (P-link)		Transmission rate:5Mbps Transmission distance:250m(electricity),3km(light)	Total extension distance:15.5km
Controller transfer (PE-link)		Transmission rate:5Mbps Transmission distance:500m(electricity),3km(light)	Total extension distance:17km
Data bus(DPCS-F)		Transmission rate:10Mbps Transmission distance:250m(electricity),4km(light)	Total extension distance:32km
Control LAN(ANS-3000)		Transmission rate:100Mbps Transmission distance:2km(light)	Total extension distance:100km FDDI standard
Control LAN(Ethernet)		Transmission rate:10Mbps or 100Mbps	Ethernet standard
