Belt Conveyor

Specifications

The Belt Conveyor is used for transferring material in bulk or container. The Belt Conveyor is widely used in the industry of mining, building materials, metallurgy, coal and so on.

Users can not only transport material with one conveyor or several conveyors, but also can transport with a horizontal/slope transfer system that made up by this kind of conveyors and other conveyors so that can meet the request of different working conditions.

The Belt Conveyor can transport materials in large quantity. The Belt Conveyor is simple in operation, convenient in maintenance, and the parts of the conveyor are in high quality.

Belt Width (mm) Conveying Length(m)/Power(kw) Transporting Speed(m/s) Capacity (t/h) 500 ≤12/3 12-20/3-5.5 20-30/5.5-7.5 1.25-2.0 40-80 650 ≤12/4 12-20/4-5.5 20-30/5.5-11 1.25-2.0 80-120 800 ≤10/4 10-15/4-5.5 15-30/5.5-15 1.25-2.0 120-200 1000 ≤10/5.5 10-20/5.5-11 20-40/11-22 1.25-2.0 200-320 1200 ≤10/7.5 10-20/7.5-15 20-40/15-30 1.25-2.0 290-480
