| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | standard container |
Specifications
Shaking table
1)Low water-absorptivity shaking table
2)Good wearability of the work surface
3)Anti-chemical corrosion
1)Low water-absorptivity shaking table
2)Good wearability of the work surface
3)Anti-chemical corrosion
1. Features of shaking table
1)Big steel intensity.
2)Low water-absorptivity.Does not increase height
3)Good wearability of the work surface.
4)Anti-chemical corrosion,acid do not avoid medicament in ore polp.
2)Low water-absorptivity.Does not increase height
3)Good wearability of the work surface.
4)Anti-chemical corrosion,acid do not avoid medicament in ore polp.
5)Good weather resistenance,good shape stablity;
6)Good selection function,good index stability.
2. Brief introduction of shaking table:
Shaking table is one of the mineral separation equipment of gracity concentrator.It is easy to be operated and can produce high grade concentrated ore,secondary concentrated ore,middlings and gangue,ect at the same time.It is widely used to separate tungsten,stannum,niobium,other rara metal and noble metal ores;It can also be used to separator iron,manganese minerals,coal,and so on.
3. Structure of shaking table:
Shaking table is made of machine head,motor,adjusting gradient device,bed,bunker,water tank,rifle bar and lubrication system.
4. Working principle of shaking table:
During the benificiation process,the mineral particles from the angle above the bed surface go to the slot,meanwhile by feedthrough fiashing water transversely.In this way,under the effect of gravity,the transverse direction running water impulsive force,and the inertia and friction created by the reciprocation symmetry of movement of the bed sueface,the ore grains are separated according to the proportion and the granularity,and makes the transversal motion along the inclined surface of bed.Therefore the ore grains with different proportion and different granularity fly heading different direction,and discharge separately from the ore concentrate end and the debris side’s two different areas,finally divided into the ore concentrate,the middling and the debris.
5. Technical parameter of shaking table:
| Name | Coarse ore surface of bed | Granulated sugar surface of bed | Ore slime surface of bed | |
| Dimension of Bed | Lentgh (MM) | 4450 | 4450 | 4450 |
| Transmission end width (MM) | 1855 | 1855 | 1855 | |
| crude ore width (MM) | 1546 | 1546 | 1546 | |
| Max Size of Feeding (MM) | 2 | 0.5 | 0.15 | |
| Feed Volume (T/H) | 30-60 | 10-20 | 15-25 | |
| Feed Density % | 25-30 | 20-25 | 15-25 | |
| Stroke (MM) | 16-22 | 11-16 | 8-16 | |
| Frequency ( F) | 45-48 | 48-53 | 50-57 | |
| Bed Surface Cross Fall | 2°30′-4°30′ | 1°30′-3°30′ | 1°-2° | |
| Dressing Area (M2) | 7.6 | 7.6 | 7.6 | |
| Bed Profile | Rectangular | Zig-zag form | ||
| Motor Power (KW) | 1.1 | 1.1 | 1.1 | |
| Driving Gear | Eccentric linkage | |||
