>Products Catalog > RF modules > KYL-300L Wireless Data Transceiver 433MHz FSK Module UART Module 433MHz RS232 Data Module
KYL-300L Wireless Data Transceiver 433MHz FSK Module UART Module 433MHz RS232 Data Module
| FOB Price: | 38.00 - 45.00 USD/Piece |
|---|---|
| Supply Ability: | 100,000 Piece/Pieces per Month |
| Shipping: | 1-3workdays |
| Payment Terms: | T/T, Western Union, Other, Paypal |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | standard |
Specifications
KYL-300L the ultra wireless transceiver data module is used as the wireless data transceiver in long-ranges, with the small size, weight and power consumption and good stability and reliability. Narrowband low power UHF wireless data transmitters and receivers with channel spacing as low as 25 kHz:
Specifications of KYL-300L
* Power output: DC 5V (customize);
* RF power: 500mW(customize);
* RF Effective Rate: 1200/2400/4800/9600/19200bps
* Interface baud rate: 1200/2400/4800/9600/19200bps optional
* Frequency Band: 433 MHz, 450MHz, 470MHz, 868MHz, 915MHz or ISM others
* Interface: standard RS-232/RS-485/USB and TTL
* Communication Mode: Half-duplex
* Offering a transparent data interface, it is suitable for any standard or non-standard user protocols
* Channel: 8(Default), 16/32(customized)
* Receive current: < 28mA(TTL connect)
* Receive sensitivity: -123dBm(at)1200bps); -118dBm(at)9600bps)
* Transmitting current: < 350mA;
* Sleep current: < 20uA;
* RF Line-of-sight Range: > 2km(BER=10-3(at)9600bps); > 3km(BER=10-3(at)1200bps)
* Size: 80mm*45mm*19mm (without antenna port).
APPLICATION:
* AMR Automatic Meter Reading
* Wireless alarm and security systems
* Building automation, security, wireless monitoring and control of room equipment, Access Control System;
* Wireless data transmission, automatic data collection system;
* Radio modem can be used for Sports training & competition;
* RF modem can be used for Electronic bus station and intelligent traffic;
* RF transmitter Wireless electronic display screen and queuing machine;
* Wireless telemetry Charging for parking, parking lot;
* Wireless modem Automobile inspection and four-wheel orientation;
* Wireless sensor Industrial wireless remote control and air conditioning remote controller;
* Data communication used for railway, oil field, dock and army.
* LED display in thruway and public places
* Point to multi-point wireless network, wireless on-the-spot bus and automatic data collection system;
