Hubei Jiangnan Special Automobile Co., Ltd.
China Manufacturer with main products: Fire Truck, Aerial Platform Truck, Wrecker Truck, Garbage Truck, Sweeping Truck, Oil Truck, Water Truck, Vacuum Suction Truck |
16th
Jiefang 4*4 Fuel Tank Truck - 22000L
| FOB Price: | 20,000.00 - 120,000.00 USD/Set |
|---|---|
| Supply Ability: | 2,000 Set/Sets per Year |
| Shipping: | within 30 days |
| Payment Terms: | L/C, T/T(Bank Transfer), Western Union |
| Place of Origin: | Hubei in China |
|---|---|
| Packaging Details: | according to customer's demand |
Specifications
| Technique parameter | |||
| Name | Jiefang 4*4 oil tank truck | L×W×H mm | 10750×2490×3250(mm) |
| Chassis Model | CA5253GJYP7K2L11T3E | Cargo body Dimension(mm) | ××(mm) |
| total mass | 25000(Kg) | Approach/Departure angle | 21/17(°) |
| Rated mass | 13000(Kg) | front/rear suspension | 1575/1800(mm) |
| curb mass | 11805(Kg) | Max. speed | 85(km/h) |
| Engine | manufacturer | displacement(ml) | ower(kw) |
|
CA6DE3-18E3 CA6DE3-22E3 CA6DF3-18E3 CA6DF3-22E3 CA6DE3-18E3F CA6DE3-22E3F CA6DF3-22E3F CA6DF3-18E3F BF6M2012-18E3 BF6M2012-22E3 |
China FAW Group Corporation
FAW Automobile Co., Ltd. Wuxi Diesel Engine Factory |
6618 6618 6740 6740 6618 6618 7120 7120 6060 6060 |
136 162 136 162 136 162 162 136 136 162 |
| Emission standards | GB3847-2005,GB17691-2005EuroⅢ | ||
| Axle | 3 | front tread | 1964/1964/1830(mm) |
| wheelbase | 2660+4715 | rear tread | 1830(mm) |
| tyre | 8 | tyre size | 9.00R20,9.00-20,10.00R20,10.00-20 |
| fuel type | diesel | spring | 4/4/4+4 |
| axle load | 6900/6900/11200 | cab passenger | 3 |
| Note |
Transport medium: gas, desnity:0.7t/m³;
Tank capacity:22.2m³,
Tank dimension (length×long axle ×short axle)(mm)8200×2420×1630 |
||
|
Special
performance |
★Our company modifies oil tank truck on the mature chassis of China. The customers may provide chassis themselves and we modify it with our component.
★Tank material: carbon steel, stainless steel, steel lined, fiberglass, plastic tanks (polyethylene)
★Tank shape: square round, oval, round
★Oil pump: self-priming pump, gear pump, chemical pump, stainless steel pump ★Fuel gauge: single count, double count, tax fuel dispenser.
★Oil tank truck can be designed into chemical tank truck .
★Oil tank truck can be equipped with computer oil machine. ★Different tons of truck can meet customer’s need. ★The tank has many anti-wave baffles and adopts high pressure gas leakage detection, so that the truck has features of high intensity, stable center of gravity and safety. |
||
|
|
|
||
