Shenzhen Sunseon Opto.Co., Ltd.
China Manufacturer with main products: LED Lights, LED Components, LED Tube Light, LED Spot Light, High Power LED, Flux LED |
5W LED Bulb (E27)
| Supply Ability: | 3,000 Piece/Pieces per Month |
|---|---|
| Shipping: | 10-15 days after receiving the payment |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Guangdong in China |
|---|---|
| Packaging Details: | CARTON |
Specifications
Product Features:
5W led bulb, higher brightness than 40W conventional incandescent lamp,
direct replacement, 80% energy saving.High luminous led source,
special design and best performance on heat sink.
high brightness output and long lifespan.
Technical Specifications:
■ Absolute Maximum Ratings (Ta = 25℃) :
|
Items
|
Symbol
|
Absolute maximum Rating
|
Unit
|
|
Operating supply range
|
Vi
|
265
|
V
|
|
Product Input Current (single LED)
|
Ii
|
380
|
mA
|
|
Power Dissipation
|
Pa
|
6.8
|
W
|
|
LED Light Source Temperature
|
Tled
|
80
|
℃
|
|
Operating Temperature
|
Top
|
-20 ~ +40
|
℃
|
|
Storage Temperature
|
Tstg
|
-40 ~ +80
|
℃
|
■ Typical Performance ( Ta = 25℃)
|
Items
|
Symbol
|
Min.
|
Typ.
|
Max.
|
Units
|
|
Product Power
|
P
|
5.5
|
6
|
6.8
|
W
|
|
Input Voltage
|
Vi
|
85
|
110/220
|
265
|
V
|
|
Product Input Current(single LED)
|
If
|
300
|
320
|
350
|
mA
|
|
Beam Pattern
|
BP
|
---
|
160
|
---
|
Deg.
|
|
Estimated Life*
|
Life
|
30000
|
---
|
---
|
hour
|
|
Optimized Thermal Management
(Body Temperature)
|
Tc
|
---
|
---
|
60
|
℃
|
Notes :
The estimated life of module with high power LED are estimated base on the module lights 4-8 hours each day , and Sunseon only guarantee 30000 hours in specification , but it is longer than 50000 hours .
■ Typical Electrical & Optical Characteristics ( Ta = 25℃):
|
Module No.
|
Color
|
LED Quantity
|
Color Temp.
|
Light output
|
|
SS-E27A00-5W-2
|
White
|
5pcs
|
5500~6500K
|
300 lm
|
|
SS-E27A00-5L-2
|
Daylight
|
5pcs
|
3800~4300K
|
250 lm
|
|
SS-E27A00-5N-2
|
Warm White
|
5pcs
|
2800~3300K
|
250 lm
|
