Jaw Crusher, Crushing Machine
FOB Price: | 1.00 - 30000.00 USD/Set |
---|---|
Supply Ability: | 10 Set/Sets per Month |
Shipping: | 30 days after down payment |
Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
Place of Origin: | Shanghai in China |
---|---|
Packaging Details: | Customary packing |
Specifications
1) High reliability
2) Flexible capacity
3) Over-loading protection
4) Easy replacement of wear and spare parts
5) Long service time
6) High efficiency
Jaw Crusher Operating principle:
The jaw crusher uses motor as its power. Through the motor's wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity composed of fixed jaw plate, movable jaw plate and side-lee board can be crushed and discharged through the discharging opening.
Working Principle of Jaw Crusher:
The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves . So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.
Models
|
Size of feed opening (mm)
|
Max
feed
size (mm)
|
Adjustable range of discharge opening (mm)
|
capacity (m3/h)
|
Power (kw)
|
Weight
(t)
|
PE-150x250
|
150x250
|
125
|
10-40
|
0.6-3
|
5.5
|
0.81
|
PE-250x400
|
250x400
|
210
|
20-60
|
3-13
|
15
|
2.8
|
PE-400x600
|
400x600
|
340
|
40-100
|
10-34
|
37
|
6.5
|
PE-500x750
|
500x750
|
425
|
50-100
|
20-52
|
55
|
10.3
|
PE-600x900
|
600x900
|
500
|
65-160
|
30-75
|
75
|
15.5
|
PE-750x1060
|
750x1060
|
630
|
80-140
|
72-130
|
90
|
28
|
PE-900x1200
|
900x1200
|
750
|
95-165
|
87-164
|
160
|
50
|
PE-1000x1200
|
1000x1200
|
850
|
195-265
|
197-214
|
160
|
51
|
PE-1200x1500
|
1200x1500
|
1020
|
150-300
|
400-800
|
200
|
100.9
|
PEX-150x750
|
150x750
|
120
|
18-48
|
5-16
|
15
|
3.5
|
PEX-250x750
|
250x750
|
210
|
25-60
|
8-22
|
30
|
4.9
|
PEX-250*1000
|
250x1000
|
210
|
25-60
|
10-32
|
37
|
6.5
|
PEX-250x1200
|
250x1200
|
210
|
25-60
|
13-38
|
45
|
7.7
|
PEX-300x1300
|
300x1300
|
250
|
20-90
|
10-65
|
75
|
11
|
