Isolation Wall System

Inquiry Now

Place of Origin:	Shanghai in China

Specifications

The special characteristics of light steel keel:

1.New Generation of grooved & rugged galvanized steel keel

2. We have passed the national authority prove,Our light steel keel compared the same material , the strength improved 28.5%

3.Ju Gang Steel Keel is patented product.The patented No. is ZL2007 3 30077666.8 & ZL2007 3 0077667.2

4.The surface content of galvanized zinc is over 100g/m2.

5.If order special size no need to pay the extral fees.

Our Spec. of metal profile / ceiling profile

Name	Spec.	Thickness	Remark
Furring Channel	50X19MM	0.4 , 0.45 , 0.5mm	New Generation grooved & Ruggled products which Zinc Coating over 100g/sqm
Main Channel	38X12MM	0.8 , 1.0 , 1.2mm
	20X12MM	0.6 , 0.8 mm
	50X15MM	1.0 , 1.1 , 1.2mm
Wall angle	20X20	0.4 , 0.6 mm
Studs	50X50	0.6 , 0.7 , 0.8 mm
	75X45MM	0.6 , 0.7 , 0.8 , 1.0 , 1.5mm
	100X45MM	0.6 , 0.7 , 0.8 , 1.0 , 1.5mm
	150X45MM	0.8 , 1.0 , 1.5mm
Tracks	50X38	0.6 , 0.7 , 0.8 mm
	75X35MM	0.6 , 0.7 , 0.8 , 1.0 mm
	100X35MM	0.6 , 0.7 , 0.8 , 1.0 mm
	150X40MM	0.8 , 1.0 , 1.5mm

The special characteristics of light steel keel:

1.New Generation of grooved & rugged galvanized steel keel

2. We have passed the national authority prove,Our light steel keel compared the same material , the strength improved 28.5%

3.Ju Gang Steel Keel is patented product.The patented No. is ZL2007 3 30077666.8 & ZL2007 3 0077667.2

4.The surface content of galvanized zinc is over 100g/m2.

5.If order special size no need to pay the extral fees.

Our Spec. of metal profile / ceiling profile

Name	Spec.	Thickness	Remark
Furring Channel	50X19MM	0.4 , 0.45 , 0.5mm	New Generation grooved & Ruggled products which Zinc Coating over 100g/sqm
Main Channel	38X12MM	0.8 , 1.0 , 1.2mm
	20X12MM	0.6 , 0.8 mm
	50X15MM	1.0 , 1.1 , 1.2mm
Wall angle	20X20	0.4 , 0.6 mm
Studs	50X50	0.6 , 0.7 , 0.8 mm
	75X45MM	0.6 , 0.7 , 0.8 , 1.0 , 1.5mm
	100X45MM	0.6 , 0.7 , 0.8 , 1.0 , 1.5mm
	150X45MM	0.8 , 1.0 , 1.5mm
Tracks	50X38	0.6 , 0.7 , 0.8 mm
	75X35MM	0.6 , 0.7 , 0.8 , 1.0 mm
	100X35MM	0.6 , 0.7 , 0.8 , 1.0 mm
	150X40MM	0.8 , 1.0 , 1.5mm

The special characteristics of light steel keel:

1.New Generation of grooved & rugged galvanized steel keel

2. We have passed the national authority prove,Our light steel keel compared the same material , the strength improved 28.5%

3.Ju Gang Steel Keel is patented product.The patented No. is ZL2007 3 30077666.8 & ZL2007 3 0077667.2

4.The surface content of galvanized zinc is over 100g/m2.

5.If order special size no need to pay the extral fees.

Our Spec. of metal profile / ceiling profile

Name	Spec.	Thickness	Remark
Furring Channel	50X19MM	0.4 , 0.45 , 0.5mm	New Generation grooved & Ruggled products which Zinc Coating over 100g/sqm
Main Channel	38X12MM	0.8 , 1.0 , 1.2mm
	20X12MM	0.6 , 0.8 mm
	50X15MM	1.0 , 1.1 , 1.2mm
Wall angle	20X20	0.4 , 0.6 mm
Studs	50X50	0.6 , 0.7 , 0.8 mm
	75X45MM	0.6 , 0.7 , 0.8 , 1.0 , 1.5mm
	100X45MM	0.6 , 0.7 , 0.8 , 1.0 , 1.5mm
	150X45MM	0.8 , 1.0 , 1.5mm
Tracks	50X38	0.6 , 0.7 , 0.8 mm
	75X35MM	0.6 , 0.7 , 0.8 , 1.0 mm
	100X35MM	0.6 , 0.7 , 0.8 , 1.0 mm
	150X40MM	0.8 , 1.0 , 1.5mm
