| Place of Origin: | Shandong in China |
|---|
Specifications
48m Truck-mounted concrete pump HDT5401THB-48/5
Main Technical Parameters In Service
Output in theory m3/h 125
Pumping capacity index Mpa.m3/h 586
Max. pumping pressure Mpa 8.5
Hopper capacity L 700
Feeding height mm 1400
Model of distributing valve S-pipe valve
Max. distributing radius m 43.7
Max. distributing height m 47.7
Max. distributing depth m 34.3
Height of boom when stretched mm 9065
Distance between front landing legs mm 9780
Distance between rear landing legs mm 9860
Distance between front & rear landing legs mm 9470
Diameter of delivery pipe mm 125
Length of tail pipe m 3
Rotary angle of boom 365
Number of boom sections 5
Rotary angle of each boom section 91/180/180/180/270
Close-control distance m 33
Remote-control distance m 200
Main Technical Parameters in Driving Condition
Max. traveling speed km/h 85
Min. turning radius mm 12000
Brake distance m 10
Approach angle 16
Departure angle 11
Chassis model HOWO ZZ5437S4667W (371 hp engine)
Wheel base between the first & the second axle mm 1800
Wheel base between the second & the third axle mm 4600
Wheel base between the third & the fourth axle mm 1350
Front tread mm 2022
Rear tread mm 1830
Max. engine power kw 275(2200r/min)
Max. engine torque n.m 1500 /(1100~1600 r/min)
Max. grade ability % 37
Fuel consumption L/ 100km 40
Overall dimension(LWH) mm 1330025004000
Total weight kg 40000
