YAG laser marking CNC system

Supply Ability:	500 Set/Sets per Month
Payment Terms:	L/C, T/T(Bank Transfer)

Inquiry Now

Related products from verified members

Vacuum Emusifying Machine

Price:

Min. Order:1 Piece
Aluminium Shot

Price:

Min. Order:1 Ton
KRD Sampler

Price:1,000.00-10,000.00 USD/Set

Min. Order:1 Set

Product Details

Place of Origin:	Hebei in China
Packaging Details:	plywood

Specifications

Character:

1.YAG laser marker machine is a solid laser machine with infrared light whose wavelength of frequency band is 1.064μm.

2. It uses krypton lamp as energy source (driving source). as a medium for producing laser, Nd:YAG can send out special wavelength to let effective substance’s level of energy jump higher so that it can let off laser.

3. With high speed scanning resonance mirror to get high precision and high speed.

4. It also can mark automatic code, sequence number, batch number, date, bar code and two-dimensional code.

5. Laser marking is non-toxic, wear and without deformation or pollution.

6. User can choose revolving worktable which is suitable to marking round products

Parameter

Parameter List
Model	YAG-50
Max. laser power	50W
Pump source	Krypton lamp
Standard marking area	75 × 75mm, 110 ×110mm, 175 × 175mm; 200 × 200mm
Repetition frequency	≤30KHZ
Cooling mode	Invariable temperature protection
Beam quality	<10m²
Marking depth	<0.3mm
Linear speed	≤7000mm/s
Min. line width	0.02mm
Min. character size	0.3mm
Repetition accuracy	± 0.01mm
Power consumed	<4.5KW
Electrical source	220V ±5% AC, 50Hz, 30A
Software language	Chinese, English
File format support	dwg, wg; dxf; bmp; jpg; png; ttf; pcx; tag; gif; plt; etc.
Work temperature	13°C ~ 28°C.
Work humidity	5% ~ 75%
