Automatic High-speed Vacuum Forming Machine AVF-4828DOT
| FOB Price: | 42000.00 - 48900.00 USD/Set |
|---|---|
| Supply Ability: | 10 Set/Sets per Month |
| Shipping: | 35DAYS |
| Payment Terms: | T/T(Bank Transfer) |
Related products from verified members
-
Price:36,000.00-40,000.00 USD/SetMin. Order:1 Set -
Price:9,000.00-10,000.00 USD/PieceMin. Order:1 Piece
| Place of Origin: | Guangdong in China |
|---|
Specifications
The Automatic High-speed Vacuum Forming Machine series of forming machinery are suitable for processing those reeling sheets including PVC, PS, PSP, PP, PET, PP etc. Under various specifications, it can be used for the forming of disposable fast-food containers, instant noodle bowls, western dinner plates, food coverings (such as sugar boxes, cake boxes and ice cream cups etc. ), articles of daily use, hardware coverings, children's toys and trays for raising seedlings of rice, vegetables and other plantations.
CHARACTER OF CONSTRUCTION:
1. The machine is combined with pneumatic, mechanical and electric drive to achieve automatic continuous process of feeding sheet, moulding, demoulding, section cutting and stacking. PLC control system makes the machine working more reliably.
2. Equipped with a feeding device of a precision retarding electric machine, and geared by a double-lined needle-point chain, this machine can achieve both accuracy and stability during high-speed operations, what is more, it is also easy to make quick adjustments so as to make good use of the plastic sheets to reduce waste.
3. Equipped with a unique divided temperature control system and a precision infrared ceramic heater, this machine can get the most stable and even temperature, and at the same time achieve electricity saving.
4. This machine also possesses some special features: It can be manually pre-started, the switch console can be moved up and down according to needs, it can achieve a delaying vacuum state or a vacuum state for a second time, and it can be put on patterns for a second time, also it can draw off patterns through shaking. All these special features can help to accelerate the forming speed and ensure the quality of the products.
5. The major electronic devices and pneumatic components are manufactured abroad, which can ensure the stability, safety and durability of this machine.
| standard specification: | |
|
Forming length
|
48’’(1220mm)
|
|
Forming width
|
28’’(710mm)
|
|
Forming height
|
about10’’(250mm, According to the different materials and mould, here is certain difference)
|
|
Production rate
|
Maximum : module / 6S
|
|
Power of oven
|
Maximum :48KW
|
|
Power of motor
|
7.5KW
|
|
Vacuum pump
|
2.2KW
|
|
Compressor
|
15KW
|
|
Total power consumption
|
About 45KW(According to the material, mould vary)
|
|
Installed power
|
75KW(Including the air compressor)
|
|
Mechanistic dimensions
|
7100*1550*2600mm
|
|
Net weight
|
About 3600KG
|
| Standard configuration: | ||
|
Pneumatic components
|
SOAR (upper and lower mold and the hot stove as a special customized bold cylinder, "PULAN")
|
|
|
Electromagnetic valve
|
SMC
|
Japan
|
|
Separated water and oil
|
SMC
|
Japan
|
|
Relay
|
OMRON
|
Japan
|
|
contactor
|
FUJI
|
Japan
|
|
Time control
|
OMRON
|
Japan
|
|
Spray gun
|
MIJI(10pcs)
|
Japan
|
|
Encoder
|
NENICON
|
Japan
|
|
Inverters
|
INOVANCE
|
Taiwan
|
|
Touch Screen
|
"WEINVIEW" (10 "color)
|
Taiwan
|
|
Control System
|
Panasonic
|
Japan
|
|
Heating system
|
Use "FULE" 60 pcs 400W ceramic infrared heat tiles, 60pcs under the furnace
|
|
|
Temperature control system
|
Independent dual-loop temperature control by PLC
|
|
|
Cooling system
|
Carrying water trays, waster transport rail, equipped with powerful centrifugal fan, 2 sets of lead air outlet trough
|
|
