4-Point Contact Thin Section, X-Type -- JU060XP0
| Supply Ability: | 100 Piece(s) per Month |
|---|---|
| Shipping: | 30days |
| Payment Terms: | L/C, D/P, T/T, Western Union, MoneyGram |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | industrial packaging |
Quick Details
- Type: Roller
- Structure: Other Structure
- Seals Type: seals
- Precision Rating: p4,p5,p0
- Outside Diameter: 0-171.450 mm
- Bore Size: 0-152.400 mm
- Brand Name: FRB
- Model Number: JU060XP0
Specifications
this X-Type series sealed thin section ball bearing is made from 52100 steel, has two seals made of molded rubber, and utilizes a snap-over cage design made of brass or composite material. this bearing is designed for applications with axial, moment, and reverse axial loads, and is manufactured to ABEC 1F precision tolerances.
Specifications
Product Category:Ball Bearings
Primary Bearing Category:Angular Contact Ball Bearing
Bearing Design
Type:Four Point Contact
Application:Aerospace; Airframe / Aircraft Control; Instrument / Miniature; Medical / Dental; Military; Radar, Scanning Equipment, etc
Dimensions
Design Units:Inch
Bore:6.0000 inch (152.400 mm)
Outside Diameter:6.7500 inch (171.450 mm)
Outer Ring Width:0.5000 inch (12.700 mm)
Overall Width:0.5000 inch (12.700 mm)
Load Ratings
Static Axial:5750 lbs (2608 kg)
Static Radial:1920 lbs (871 kg)
Dynamic Axial:3220 lbs (1460 kg)
Dynamic Radial:1290 lbs (585 kg)
Speed Ratings:Oil 1570 rpm
Material / Plating:Stainless Steel (optional feature); Ceramic Races (optional feature); Corrosion Resistant (optional feature)
Rolling Element:Steel; Stainless Steel (optional feature); Ceramic Balls (optional feature)
Seals / Shields:Double Seal
Bearing Class:ABEC1 / Class 0 / P0; ABEC3 / Class 6 / P6 (optional feature); ABEC 5 / Class 5 / P5 (optional feature); ABEC 7 / Class 4 / P4 (optional feature)
Lubrication:Prelubricated; Solid Lubrication (optional feature)
Features:Thin-section; Flanged (optional feature); Snap Ring / Snap Ring Groove (optional feature)
Operating Temperature:-65 to 250 F (-54 to 121 C)
