LJZ2-CNS-500*5000 Double-head Precision Cutting Saw CNS
| FOB Price: | 1,000.00 - 10,000.00 USD/Set |
|---|---|
| Supply Ability: | 100 Set/Sets per Quarter |
| Shipping: | two days |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Shandong in China |
|---|
Specifications
Equipment feature
■used for not only aluminum profile and curtain wall profile cutting ,but also comerconnector cutting.
■feeding system adopts imported linear guide pair,with high accuracy and long service sife.
■right head feeding adopts hihg helical pitch ball screw -lead motion,with high accuratedriving locating and smooth working.
■adopt cnc technique,can achieve various profiles auto cutting off .
22.5° 45° and 90°cutting is available .
■imported carbide saw blade give accurate processing and hihg endurance.
■imported linear bearing motion pair ensured steady processing accuracy.
■saw blade rotate smoothly due to high accuracy main spindle.
■uniform sped feeding and smooth motion due to airdraulic damping cylinder.
■auto-opening guard shield ensurde safety operation.
■used for not only aluminum profile and curtain wall profile cutting ,but also comerconnector cutting.
■feeding system adopts imported linear guide pair,with high accuracy and long service sife.
■right head feeding adopts hihg helical pitch ball screw -lead motion,with high accuratedriving locating and smooth working.
■adopt cnc technique,can achieve various profiles auto cutting off .
22.5° 45° and 90°cutting is available .
■imported carbide saw blade give accurate processing and hihg endurance.
■imported linear bearing motion pair ensured steady processing accuracy.
■saw blade rotate smoothly due to high accuracy main spindle.
■uniform sped feeding and smooth motion due to airdraulic damping cylinder.
■auto-opening guard shield ensurde safety operation.
|
Working air pressure
|
0.4-0.6 Mpa
|
|
Power supply
|
380V 50HZ
|
|
Air consumption
|
200 L/min
|
|
Input power
|
5.9KW
|
|
Saw blade diameter
|
Φ500×Φ30×4.5
|
|
Saw plate rotative velocity
|
3100 r/min
|
|
Cutting width
|
135 mm
|
|
Cutting height
|
200 mm
|
|
Cutting range
|
400-4200 mm
|
|
Overall dimensions
|
5500×1700×1800 mm
|
|
Weight
|
2100 kg
|
