Metal Mould Machine JCUT-5060

Supply Ability:	20 Set/Sets per Month
Shipping:	by sea
Payment Terms:	T/T, Paypal, Western Union

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	Wooden trunk for export

Specifications

Metal Mould Machine JCUT-5060

Metal Mould Machine Application:

Mould Machine is used for the processing of metal mould , graphite electrode, mobile phone, camera and MP3.

Optional models: 4030, 5040, 6060, 8080

Used for the processing of metal mould , graphite electrode, mobile phone, camera and MP3.

Optional models: 4030, 5040, 6060, 8080
1. Whole cast-iron structure, steady structure, high rigidity, precision 0.01mm.
2. Three axis all use Germany ball screw and Taiwan linear orbits, also installed with Japan bevel math bearing for ball screw to make sure the accuracy and reposition precision.
3. Imported NK200 system, This system has break point memory mode and special saving mode of different points, so that can make sure continuous working after electronic drop or other postpone situation. The function can guarantee the processing precision of long time operation..
4. Adopt table movement to keep stable.
5. Adopt high-speed water cooling variable frequency motor, big torque, strong cutting, high-frequency , long-lifetime, can be a long time continuous working .

Mould Machine Parameters:

JCUT MODEL	JCUT-5060 CNC Milling Machine
Working Area (XYZ)	500X600X30mm(19.6X23.6X11.8 inch)
Table size	650X750mm
Processing accuracy	0.015mm/300mm
Repositioning accuracy	0.015mm/300mm
Lathe structure	Cast iron
Table structure	Cast iron
Spindle	2.2KW Constant power variable speed , water-cooled
Spindle rotating speed	0-24000rpm/min
Max Moving Speed	12000mm/min
Working speed	0-8000mm/min
Driving mode	XYZ-Ball screw
Voltage	AC220V/50Hz
Max. Power consumption	3.5KW
Feeding Height	300mm
Drive motor	Servo
Command	G. Code , mmg , plt , uoo, HPGL
Compatible Software	ArtCAM, masterCAM UG software
Certificate	CE, FDA
Pack dimensions	1400mm X 1400mm X 2000mm wooden trunk
Net weight	1800KG
