Radial Contact Thin Section, C-Type -- JU070CP0
| Supply Ability: | 100 Piece(s) per Month |
|---|---|
| Shipping: | 30days |
| Payment Terms: | L/C, D/A, T/T, Western Union, MoneyGram |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | Industrial packaging |
Quick Details
- Type: Ball
- Structure: Other Structure
- Seals Type: seals
- Precision Rating: p4,p5,p0
- Outside Diameter: 0-196.850 mm
- Bore Size: 0-177.800 mm
- Brand Name: FRB
- Model Number: JU070CP0
- Number of Row: Single Row
Specifications
this C-Type series sealed thin section ball bearing is made from 52100 steel, has two seals made of molded rubber, and utilizes a snap-over cage design made of brass or composite material. this bearing is designed for applications with primarily radial loads, and is manufactured to ABEC 1F precision tolerances.
Product Category:Radial Ball Bearings
Type:Conrad / Deep Groove Thin-section
Application:Aerospace; Airframe / Aircraft Control; Instrument / Miniature; Medical / Dental; Military; Radar, Scanning Equipment, etc
Dimensions
Design Units:Inch
Bore:7.0000 inch (177.800 mm)
Outside Diameter:7.7500 inch (196.850 mm)
Width:0.5000 inch (12.700 mm)
Overall Width:0.5000 inch (12.700 mm)
Load Ratings
Static Axial:5120 lbs (2322 kg)
Static Radial:2560 lbs (1161 kg)
Dynamic Axial:4550 lbs (2063 kg)
Dynamic Radial:1570 lbs (712 kg)
Speed Ratings:Oil 2170 rpm
Bearing Class:ABEC 1 / Class 0 / P0; ABEC 3 / Class 6 / P6 (optional feature); ABEC 5 / Class 5 / P5 (optional feature); ABEC 7 / Class 4 / P4 (optional feature)
Material / Plating:Stainless Steel (optional feature); Ceramic Balls (optional feature); Corrosion Resistant (optional feature)
Seals / Shields:Double Seal
Features:Prelubricated; Solid Lubrication (optional feature); Flanged (optional feature); Snap Ring / Snap Ring Groove (optional feature)
Operating Temperature:-65 to 250 F (-54 to 121 C)
