Home  >Products Catalog > ATC CNC Router > JIAXIN Door engraving machine (JX-1325T)

JIAXIN Door engraving machine (JX-1325T) SafeBuy Supplier Member

FOB Price: 7,000.00 - 15,000.00 USD/Set
Supply Ability: 60 Set/Sets per Month
Shipping: within 15 days
Payment Terms: L/C, T/T, Western Union
Update Time: 2016/9/6
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Shandong in China
Packaging Details: Steel frame and plywood box

Quick Details

  • After-sales Service Provided: Engineers available to service machinery overseas
  • Warranty: 12 months
  • Certification: CE,CIQ,QC,SGS,SAI
  • Weight: 2000KGS
  • Power(W): 4.5KW
  • Voltage: AC380V/50Hz ,others optional
  • Model Number: JX-1325T
  • Brand Name: JIAXIN
  • CNC or Not: CNC
  • Condition: New

Specifications


Door engraving machine JX-1325T

Specification
Model
JX-1325T
X .Y Axis working area
1300X2500mm
Z-Axis working area
200mm
Repeatability
0.025(+/-mm)
Max Cutting Speed
30000mm/min
Rapid Traverse
50000mm/min
Spindle power rate
  4.5KW (HSD , air cooling)
  Spindle rotating speed
0-24000rpm
command
G code*.u00*.mmg*plt
Work Mode
Step Motor
Control system
Nc studio
Transmission
Rack and pinion
Guide way
Square (PMI/HIWIN)
Power
AC380V/50Hz


Suitable Industry
Suitable for high-volume processing of non-ferrous metal sheet, Such as aluminum veneer, aluminum composite panel,
copper, PVC board, acrylic, insulation materials, wood and composite panels such as sheet processing, cutting, slotting,
engraving, milling, etc.
Performance Characteristics
1.Imported Linear Square Guide way, Double-line Four-row Slider, Undertake Heavy-duty, Stable operation, High precision,
Long lifetime, cutting with high precision
2.Change tools by cylinder, work fast and steady. Low cost than the machine with ATC.
3.High-speed drive a stepper motor and driver, Y axis using a dual-motor drive, to make high-speed operation up to 25 meters
above the blank line speed, with the cutting spindle can greatly enhance the carving is even more. It is with 3 water cooled
spindle ,it can work auto change the spindle.
4.Software: compatible with Type3/Artcam/Castmate / Ucancam a variety of CAD / CAM Design Software

Guarantee & after sale service
Guarantee for one year,24-hour technical support by email or calling
User-friendly English manual and Video CD for machine using and maintaining.
