MAG MIG welder

Supply Ability:	10,000 Piece/Pieces per Month
Shipping:	with in 30 days
Payment Terms:	T/T(Bank Transfer)

Inquiry Now

Product Details

Place of Origin:	Shaanxi in China
Packaging Details:	carton

Specifications

Features
Single-phase,portable,fan-cooled wire welding machine for flux(no gas) and MIG/MAG(gas)welding
With thermal protection,complete with MIG welding accessories.
The kit for welding different types of materials such as steel,stainless steel.
Steel and aluminum is available on request.

Item	MIG105	MIG130	MIG150	MIG175	MIG195
Power voltage(V)	230	230	230	230	230
Frequency(HZ)	50/60	50/60	50/60	50/60	50/60
Max absorbed power(KVA)	2.5	3.6	3.7	5.2	6
Absorbed Power 60%(KVA)	1.1	1.3	1.4	2.3	2.5
Mains fuse(A)	10	13	16	16	16
Power factor	0.9	0.9	0.9	0.9	0.9
Max no-load voltage output(V)	32	33	34.2	35.8	37
Current range output(A)	50-100	50-120	60-140	60-160	60-180
Max current output	80@10%	105@15%	115@15%	140@15%	140@20%
Adjustment positions	4	4	4	4	4
Core welding wire diameter	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Steel welding wire diameter	0.8	0.8	0.8	0.8	0.8
Aluminum welding wire diam	0.8	0.8	1.0	1.0	1.2
Insulation class	H	H	H	H	H
Measurement(MM)	535x265x410	535x265x410	595x340x410	595x340x410	595x340x410
Weight(KGS)	30	32	35	37	38
Cod.(NO)	893014	893015	893016	893017	893018
