Polyester Printing Mesh for Screen Printing

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

Monofilament polyester is woven from yarn that is extruded from heated polyester into a single strand. The extruded thread is the spun to a precise diameter. Conventional monofilament polyester screen fabric will elongate under tension: the higher the tension level, the more the thread can stretch. At excessive tension levels, the thread reaches its "plastic deformation" point, and the screen will no longer hold tension.

MF monofilament polyester screen printing mesh (bolting cloth) in low-elongation and high tensile strength with a wide range of mesh counts and significant advantages compared with traditional polyester mesh.

Our produce range form 15mesh(6T)-420mesh(165T), width :0.6m to 3.9m ,and three color available : White, Yellow and Black

General Specification of Monofilament Polyester Printing Mesh: 15mesh/inch,25mesh/inch, 30mesh/inch, 38mesh/inch, 45mesh/inch, 55mesh/inch, 60mesh/inch, 75mesh/inch, 80mesh/inch,90mesh/inch, 100mesh/inch, 110mesh/inch, 120mesh/inch, 135mesh/inch, 137mesh/inch, 140mesh/inch, 150mesh/inch, 155mesh/inch, 160mesh/inch, 175mesh/inch, 180mesh/inch, 195mesh/inch, 200mesh/inch, 230mesh/inch, 250mesh/inch, 280mesh/inch, 305mesh/inch, 355mesh/inch, 380mesh/ inch, 420mesh/ inch.

Normal Specification of Maishi Monofilament Polyester Printing Mesh (Bolting Cloth)
model	mesh count	APERTURE	THREAD DIAMETER	OPENING	thickness	INK THROUGH VOLUME THEORETICALLY
model	mesh/inch	micron	micron	%	micron	cm³/m²
6-400	15	1300	400	65	780-810	560
10-250	25	700	250	49	508-518	355
12-250	30	610	250	53	495-505	305
15-250	38	467	250	49	489-501	213
18-150	45	410	150	53	255-275	138
21-150	55	330	150	46	260-280	123
24-100	60	316	100	57	136-145	109
24-120	60	302	120	51	230-240	104
30-120	75	213	120	41	235-345	102
32-100	80	212	100	46	145-155	69
36-90	90	183	90	44	160-165	65
39-55	100	195	55	56	88-96	55.0
39-80	100	166	80	43	125-130	59.0
43-80	110	147	80	40.8	127-132	53
48-70	120	135	70	41	108-120	45.5
54-55	135	118	55	47	88-96	44.5
54-64	135	115	64	38.5	95-105	38.9
54-70	135	108	70	34	108-120	40
58-55	145	118	55	38	89-94	39.5
61-64	155	105	64	42	98-107	33
64-45	160	105	48	43	73-82	36.5
64-55	160	98	55	38	85-95	36.1
64-64	160	88	64	30	95-105	30.7
68-55	175	85	55	34	85-90	29
72-48	180	90	48	36	75-84	33.1
77-55	190	81	55	30	88-97	26.6
80-45	200	75	45	36	65-74	27.7
80-48	200	72	48	33	75-84	28.7
90-48	230	56	48	25	77-85	23.5
100-40	250	58	40	33	62-71	21.3
110-40	280	48	40	27	65-71	18.4
110-34	280	54	34	35.5	52-57	20.2
120-34	305	45	34	30.5	52-57	18.4
140-34	355	31	34	19.5	56-62	14.4
150-31	380	36	31	29	43-47	13.1
150-34	380	30	34	20.5	56-62	14.9
165-31	420	31	31	23	52-58	12.88

Notice: Other abnormal specification can be produced if the quantity more than 3000sqm

D (DENIER) =MICRON

9D=31MICRON,12D=34MICRON,16D=40MICRON,22D=48MICRON,30D=55MICRON;

40D=64MICRON, 50D=70MICRON,60D=80MICRON,80D=90MICRON,100D=100MICRON
