Product Details

Place of Origin:	Jiangsu in China
Packaging Details:	standard export package

Specifications

Product Description

Model: CS-400SL fully automatic metal circular sawing machine

Specification and Capacity

Features:

CS-400SL fully automatic metal circular sawing machine, the thin pipes will not be clamp flat, suit for the thin pipes, furniture pipes and sporting pipes, high efficiency.
Features:

- Vertical sideways cutting feed makes the cutting steady and the saw durable
- Special design, many groups of tooth gearing, suit to heavy duty cutting, the accuracy is steady
- Special designed feeding system, the feeding length set to 6-640m/mz(can feeding 3 times)
- Use PLC controller, no connection point and easy repairing
- It stop automatic without material
- The structure is stable, low vibration and the machine is durable
- The cooling fluid circles automatic and makes the cutting section smooth.
- The cutting scraps are treated together and the maintenance is easy.

Technical Specification and Capacity

Model			CS275SL	CS315SL	CS350SL	CS400SL
Main motor			2/4 pole 2/2.4KW	2/4 pole 2/2.4KW	2/4 pole 2/2.4/3KW	2/4 pole 2/2.4/3KW
Main shaft rotating speed			96/48	88/44	48/19	38/19
Suitable saw Blade	OD		Φ250 – 300 mm	Φ250 – 350 mm	Φ250 – 370 mm	Φ250 – 400 mm
	Center Bore		Φ32	Φ32	Φ32	Φ32
	Pin hole		2 x Φ11x65mm PCD	2 x Φ11x65mm PCD	2 x Φ11x65mm PCD	2 x Φ11x65mm PCD
Feeding length			750 x many times
Oil pump system			2.2KW,Pole motor, double –ply pump operating pressure 25-35kg/cm
Cooling system			0.09Kw motor, automatic cooling circulation
Compress air			0.0 – 0.9 Mpa 160N/min
Weight			1100 KGS	1300 KGS	1400 KGS	1500KGS
Packing size
Cutting capacity as reference
sawing profile scale			Φ80	Φ110	Φ125	Φ150
			60 x 60	90 x 90	110 x 110	125 x 125
			60 x 80	90 x 90	110 x 110	125 x 125
			60 x 80	90 x 90	110 x 110	125 x 125
			Φ38	Φ55	Φ75	Φ100
			38	50 x 50	65 x 65	80 x 80
			Using special designed clamping mould, according to diameter to cut 2 – 9 pieces /time
		Special mould dies are not standard configuration should make to order
