Wuxi Shengbang Electronics Co., Ltd.
China Manufacturer with main products: Sensor, EGR Valve, Instrument Cluster |
Speed Sensor
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
Specifications
Output resistance: 1260Ω ±10% (20℃ )
Output inductance: 610 mH ±10% (20℃ )
Output signal: sine wave signal output
At low speed of 40 r/min, the output peak voltage shall be no less than 300mv At high speed of 7000r/min, the the output peak voltage shall be no more than 170v
Installation distance: 0.55mm～1.5mm to the top of the gear teeth
Rotation range: 400～7000r/min
Measuring accuracy: 0.2%
Using temperature: -40℃ ～+130℃
Environment humidity: 0-95%
Structure: water-proof; oil-proof
Electric connectors: cable leading out (AMP C282191)
Insulation resistance: more than 50 MΩ
Shell material: PA6 reinforced nylon
Vibrating influence: Vibration from any direction with a frequency of 10～200Hz and a displacement range of 0.35mm would result in an error less than
0.1% of the measuring range.
Magnetic field influence:
In an external magnetic field with a frequency of 50Hz and the density of 400A/m, the maxim error shall be less than 0.1% of the measuring range.
