Marble/Tile/Granite CNC Carving Router JCUT-9090C
| Supply Ability: | 100 Set/Sets per Month |
|---|---|
| Shipping: | by sea |
| Payment Terms: | T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wooden trunk for export |
Quick Details
- Condition: New
- Engraving Area: 900mm*900mm
- Engraving Speed: 0-4000mm/min
- CNC or Not: Yes
- Cooling Mode: Water Cooling
- Brand Name: JCUT
- Model Number: 9090
- Dimension(L*W*H): 1400mm X 1400mm X 1650mm
- Certification: CE
- After-sales Service Provided: Engineers available to service machinery overseas
Specifications
Marble/tile/granite cnc carving router JCUT-9090C (35.4X35.4X 11.8inch)
This marble/tile/granite cnc carving router series of models are mainly used for heavy stone engraving and carving.
Applicable industry: stone, tombstone processing, advertising, decoration, wood furniture, handicraft industries. It can be for murals, marble, granite, tombstone, milestones, tile and other stone carvings for text and graphics engraving and relief. glass, wooden fish stone and other hard materials engraving and cutting.
Performance Features:
1.Three axes adopt import linear orbit, two line sliding track, heavy loading, stable working, high precision, long lifetime .
2. Whole seamless weld steel structure, not easy to distort, the table back lining is armor plate, good rigidity, the machine can bear 1MT weight at least.
3. Constant power spindle and motor, high cutting capability, high efficiency.
4. Well compatibility, compatible software CAD/CAM, such as Type 3, Artcam,Castmate,Artcam,Coredraw.
5. Double direction cutters cooling system can prolong the lifetime of using.
6. High flexibility, uneasy distorted cable and imported electronic components guarantee the stability of operating the machines.
Parameters:
Working Area (X*Y*Z):900X900X300mm (35.4X35.4X 11.8inch)
Table size: 1000x1000mm
Processing accuracy: 0.03mm
Repositioning accuracy: 0.02mm
Spindle: 4.5 KW constant power spindle
Spindle rotating speed: 0-24000rpm/min
Max Moving Speed: 7000mm/min
Working speed: 0-4000mm/min
Driving mode: rack
Voltage: AC220V/50Hz
Max. Power consumption: 6.2KW
Feeding Height: 300mm
Drive motor: stepper motor
Command:G.code , mmg , plt , uoo,HPGL
Control software: Ncstudio
Compatible Software: Type3, Artcut, ArtCAM, masterCAM software
Certificate:CE, FDA
Pack dimensions: 1400mm X 1400mm X 1650mm wooden trunk
Net weight: 390KG
Option: Rotary axis, servo motor, bigger spindle.
Different working size:
600X800mm/600X1500mm/900X1500mm/1200x1200mm/1200x1500mm/
1200x1800mm/1200x2400mm/1500x3000mm or other sizes according to customers'
