TC6013 6T Hammerhead Tower Crane Zoomlion Mast Setion in EXW FOB CIF Price

FOB Price:	51,600.00 - 60,000.00 USD/Set
Supply Ability:	80 Set(s) per Month
Shipping:	15-20 days at Qingdao port
Payment Terms:	L/C, T/T, Western Union, 30% deposit in advance and the balance by the copy

In Stock

Inquiry Now Start Order

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	container

Quick Details

Feature: Tower Crane
Certification: ISO, CE, EAC
Brand Name: AVITT, HYCM
Max. Lifting Height: 150M
Max. Lifting Load: 6T
Condition: New
After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 12 MONTH
Model Number: TC6013
Span: 60m
Rated Lifting Moment: 800 kn.m
Rated Loading Capacity: 6t
Application: Building Conatructions

Specifications

TC6013 6T Hammerhead Tower Crane Zoomlion Mast Setion in EXW FOB CIF Price

as a professional supplier of Overhead Crane, we attribute the popularity of this product to the following details:
1.QTZ6013 Topkit Tower Crane / Overhead Crane
2.Max.Load: 6T
3.Tip load: 1.3T
4.Jib length:60m
5.CE/ISO Certification

QTZ80(TC6013) tower crane is new designed self-erecting top slewing tower crane.
1.Advanced technical parameters, max. Radius is 60m, max. Height is 150m. Good looks, popular in China and the world.
2.Various working ways, stationary, external climbing and inner climbing types, is widely used in different construction sites. the static height is 46m, it can reach up to max. Height 150m by increasing mast sections and anchorages.
3.Speeds of trolleying and slewing mechanisms are high, good speed adjusting performance, excellent stability.
4.Imported electronic control system, service life is 3-4 times than national assemblies, less faults, simple maintenance, reliable work.
5.Light structure, good stability, convenient transportation; Mast sections are SAW welding, safe and reliable. Advanced mechanisms, equipped with various safety devices, mechanical or Mechatronics products work in wretched conditions to keep tower cranes work well.
6.Advanced electronic appliances.
7.Equipped with excellent safety devices produced by world-class technology, including weight limiter, moment limiter, height limiter, radius limiter, slewing limiter, slewing and trolleying brakes.
8.Anti-broken wire rope device and anti-broken shaft device
9.the rope controlling system of hoisting mechanism

Rated Lifting Moment(KN.M)	800
Rated Loading Capacity(t)	6
Max. Lifting Load(t)	6
Tip Load(t)	1.3
Max. Lifting Height(m)	150
Span(m)	60
Free standing height(m)	45
Rope length(m)	400
Working range(m)	3-60
Slewing speed(r/min)	0.6
Power supply	380V/50Hz
Power Capacity(kw)	48.2
Electric switch box	Schneider
Hoisting speed(m/min)	(a=2)80/40/8.5 (a=4)40/20/4.25
Mast section dimensions(m)	1.6x1.6x2.8 (block structure)
Main materials(mm)	135X12(square steel, Q355B)

We are looking forward to cooperating with you soon. Warmly welcome for your contact.
