32 port 256 sims gsm channel bank

Shipping:	7 days
Payment Terms:	T/T(Bank Transfer), Western Union, PayPal

Inquiry Now

Related products from verified members

Optical Imaging Touch Screen

Price:100.00-1,000.00 USD/Set

Min. Order:1 Set
1.25G SFP Bi-Di Optical Transceiver

Price:60.00-135.00 USD/Pair

Min. Order:1 Pair
FBT Splitter (1x32)

Price:

Min. Order:
TS RE-Multiplexer (with IP output)

Price:

Min. Order:1 Piece
SMA905 Fiber Optic Patch Cord UVHCS300um Armour...

Price:48.00 USD/Piece

Min. Order:1 Piece

Product Details

Place of Origin:	Shenzhen in China

Specifications

Our company designed to meet the VOIP gateway on the car floor with the
research and development production of GSM / CDMA gateways, voice clarity,
anti-polarity accurate, stable quality, do not crash. Same parameters as PSTN.

PXGT3201 32-ports 256 cards fixed wireless terminals

Using the latest technology to make devices to modify the IMEI automatically. 256
cards can be switched automatically. Switching is flexible, according to call numbers,
talking time, standby time, or a specified time to switch automatically . Effective
break blockade

It is a 32 channels with 256cards GSM Gateway that has 32 ports FXS interfaces.

It can connect with basic telephone set, PBX or VOIP Gateway etc. call system

Features:

Dialing tone frequency:450hz

Employ Industrial module (sim340) to make

SIM card supported (1.8V, 3V)

Caller ID display

DTMF Dialing

Bell signal

Polarity reversal

The RJ-11 socket which connect the phone or billing system for metering purpose

Antenna socket (SMA)

IP Presetting.

Working status indicator

Signal Strength indicator

Technical Specifications

Air interface standard: GSM850/1900Mhz,900/1800Mhz phase 2+ full band

Frequency ranges:

A) GSM 850 GSM 1900:

I) Transmission: 869.2 ~ 893.8MHz I) Transmission: 1, 930 ~ 1, 990MHz

Ii) Reception: 824.2 ~ 848.2MHz Ii) Reception: 1, 850 ~ 1, 910MHz

B) GSM 900: GSM 1800:

I) Transmission: 890 ~ 915MHz I) Transmission: 1, 710 ~ 1, 785MHz

Ii) Reception: 935 ~ 960MHz Ii) Reception: 1, 805 ~ 1, 880MHz

Phone interface: supply RJ-11 Phone Interface

Hanging voltage: 45V

Picking off voltage: 30mA / 41mA

Dialing tone Frequency: 450Hz

Antenna interface: Antenna amplifying>1.5db

Sensitivity:<-104DBM

Transmitting power<3W

Adapter interface:INPUT:AC 175~260V

OUTPUT:+5V/1000MA

Operation Circumstance:

Operation temperature: -10c~60C

Storage temperature:-20C~70C

Operation humidity:45%-95%

Atmosphere pressure:86-106Kpa

Environment noise: <60DB

Transmitting Power:2W

Sensitivity: <-104dbm

Antenna Amplifying: >1.5db

Dialing frequency: 450Hz

Hanging voltage: 45V

Picking current: 30mA/41mA

Package:

Product dimension: L500x W390 x H110mm

G.W: 15kg
