Solar Pressure Water Tank
| Supply Ability: | 5,000 Pack/Packs per Month |
|---|---|
| Shipping: | 15 working days after the recepit og deposit payment |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Jiangsu in China |
|---|---|
| Packaging Details: | Cartons |
Specifications
1. Split solar pressure water tank
2. CE certified
3. Low heat loss
4. Food grade SUS 304 or SUS 316 inner vessel
Split solar pressure water tank (MRPS) is specially designed to be compatible with solar water heating systems. Tanks range from 100L to 300L and they could come with or without copper coil heat exchanger. All tanks are CE certified.
----------------------------------------------------------------------------------------------------------
Specification of split pressure water tank (MRPS):
| MODEL | MRPS-100 | MRPS-150 | MRPS-200 | MRPS-250 | MRPS-300 |
| Volume | 100L | 150L | 200L | 250L | 300L |
| Inner Vessel Diameter(mm) | φ360 | φ360 | φ470 | φ470 | φ470 |
| Water Tank Dimension(mm) | φ470 | φ470 | φ560 | φ560 | φ560 |
| Material And Thickness Of The Inner Vessel | SUS304 1.2mm | SUS304 1.2mm | SUS304 1.5mm | SUS304 1.5mm | SUS304 1.5mm |
| Material And Thickness Of The Shell | color steel sheet 0.55mm | color steel sheet 0.55mm | color steel sheet 0.55mm | color steel sheet 0.55mm | color steel sheet 0.55mm |
| Insulation And Thickness(mm) | polyurethane 55mm | polyurethane 55mm | polyurethane 55mm | polyurethane 55mm | polyurethane 55mm |
| Installation Size Of Water Pipe | NPT3/4" | NPT3/4" | NPT3/4" | NPT3/4" | NPT3/4" |
| Overall Dimension(mm) | φ470×975 | φ470×1430 | φ560×1210 | φ560×1500 | φ560×1775 |
| Packing case size(mm) | 575×530×1077 | 575×530×1535 | 640×620×1250 | 640×620×1630 | 640×620×1882 |
| Weight(Kg | 21KG | 27KG | 35KG | 44KG | 47KG |
| Pressure | 0.8MPA | 0.8MPA | 0.8MPA | 0.8MPA | 0.8MPA |
| Electrical Heating Element | 1.5KW | 1.5KW | 1.5KW | 1.5KW | 1.5KW |
