Sweeping and Primer Spraying road Machine

Inquiry Now

Related products from verified members

Product Details

Place of Origin:	Henan in China

Specifications

1. Engine: Japanese Robin 6.0HP or Honda 5.5HP four-stroke air-cooled gasoline engine.
2. Air compressor: 0.2m3/min the piston type abrasion resistance air compressor ensures the flow much larger and the pressure more stable.
3. Flow: 3.5L /min.
4. Primer storage pot: 0.8Mpa pressure and equipped with pressure safety valves .The capacity is 40kg. There is a sieve in the feeding port.
5. Spray gun: The new type spray gun controlled by handle owns hard side columnar reverse wash nozzle, which ensures removing plug conveniently and quickly; the non-arc nozzle ensures the base line neat. Spray width :100-450mm.
6. Chassis: A firm welded frame, whose surface has been chrome-plated or coated by corrosion resistance spraying treatment. Equip with imported bearing which ensures the whole machine running lightly and more convenient.
7. Rubber wheel: Left, right front wheel and rear wheel are special natural modified rubber wheels. The front wheel diameter isΦ240mm; rear wheel diameter isΦ190mm.
8.Guide rod: Adjust freely in all directions, up, down, left or right.
9. Handle bar: The height of handle can be freely adjusted according to the needs of operator.
10. Rear wheel directional device: Lockable directional device can ensures the road-marking machine moving in straight lines and turning freely in curved road.
11. This machine is not only used for spraying primer, but also for cleaning the road surface before marking without primer.
12. Size & Weight: 1260mm (L) x 1000mm (W) x 1000mm (H), 110kg.

Road marking machines manufactures in china.Supply thermoplastic road marking machines, cold solvent road marking machines and road marking paints, reflective paints, traffic paints, traffic lights.
