All scanner

ALL SCANNER

® AS800ALSCAN (VCX® interface) offers a superset of ALSCAN2534 functionality. It supports standard PassThru communication, plus hosts applications internally, plus adds two protocols, plus extra voltages needed for ECU reprogramming, wireless ethernet, or GPS modules.

ALLSCANNER® TECHSCREAM compatialbe GTS contains north americal and europe version with mutiple language support, North America version = English, French, Spanish,  urope version = English, German, French, Spanish, Italian, Chinese

Standalone operations
ALLSCANNER runs it’s own operating system which allows it to be used as a standalone tool without a PC attached during operation. Imagine writing your own C/C++ application to perform an on-road test, then use 802.11A/B/G WiFi to wirelessly download a vehicle’s data as soon as it re-enters the repair facility. Your program could access GPS compact flash card to capture location information about the test-drive, or use a cellular modem and download telemetry from live tests! For standalone applications, this provides the features of a PC host and a PassThru device all in one package.

Software Vedix®
Software Specification Vedix® is the latest diagnostic software platform of ALLScanner® to work with the hardware of VCX®, the characters be shown as below:
* Diagnostic software can be operated under WinCE and Windows, available installation for Laptop or PDA.
* Automotive Diagnostic language (VDL) exploitation platform based on XML by self-determination and high efficiency database management system, these will make it easily to explore the vehicles.
* Continuously update for diagnostic software remotely.

Customers Applications
* J2534 Independent Repair Facility tool
* Diagnostics using 3rd party applications *
* In-vehicle pass-thru data logging
* Standalone data logging or monitoring
* Fleet or public transportation data acquisition
* OEM Engineering
* OEM calibration reprogramming
* End-of-Line testing
* Dealer Service Tools
* 3rd party integrated solutions
* Specialized Customers

Hardware VCX® interface
CPU                     16 digit Dual Cell specialize CPU
RAM                     64KB RAM
FLASH                   256KB FALSH
Diagnostic Port         24PIN, self-determination design
Wireless Port           802.11b/g WIFI wireless
LED                     4 LED indicator light,indicate power and
status.
Power                   DC 9V-28V
Consumption             3W
Size                    156(L)x86(W)x35(H)mm
Working Temperature     -20 to +70degrees
StorageTemperature      -40 to 85degrees

Package including:
VCX® interface
Software Vedix® work with tens of cars
Cables for cars communication
10" tablet PC with TIS TECHSCREAM (optional)
Power supply
Carrying case

Tablet PC specification
* CPU  VIA C7-M® Mobile processor 1.2GHz
* Memory   1G
* Storage device HDD 30G 1.8inch
* Display 7" 16:9 touch TFT, with solution 800*480
* Audio Device Input: built-in mic input interface
* Vedio Device built-in high definition 300K webcam
* Network Device 10/100 MB ethernet interface, built in
 wifi, Support IEEE 802.11.B/G standard
* Battery 2200MA/10.8V Li-battry,working hour :2-3H
* Input Device touch and hand-writing panel
  support USB2.0 built-out mouse,high sentisitive touch pad
*Interface USB connection: USB2.0 X 3
* Vedio interface: VGAX1
* Audio interface :ф3.5mm/40mw X 2 stereo earphone
  output,ф3.5mm/-56dB mic input
* Network  interface: RJ-45
* SD/MMC storage extension slot ,max extension to 32GB
  DC19V/3A adapter

Why ALLSCANNER® ?
* Handy package with a small tablet
* User friendly software
* General diagnose plus professional diagnose 2in1 package
* Update via internet
