| Place of Origin: | Guangdong in China |
|---|
Specifications
|
* Image Sensor
|
1/3” SONY SUPER HAD CCD;
|
|
* Resolution
|
420TVL~700TVL(Optional);
|
|
* Lens
|
9-22mm Manual Zoom Lens;
|
|
* LED
|
￠10mm×12PCS;
|
|
* IR Distance
|
80m;
|
|
* Waterproof
|
IP66;
|
|
* Bracket
|
3 Axis Bracket;
|
|
* Other
|
External lens adjusting.
|
|
Model
|
SA-1504
|
|||
|
Image Sensor
|
1/3” Sony SUPER HAD CCD
|
|||
|
TV System
|
PAL/NTSC
|
|||
|
Effective Pixel
|
PAL:500(H)×582(V)
NTSC:510(H)×492(V) |
PAL:752(H)×582(V)
NTSC:768(H)×494(V) |
PAL:795(H)×596(V)
NTSC:811(H)×508(V) |
|
|
Horizontal Resolution
|
420TVL
|
540TVL
|
600TVL
|
|
|
Minimal Illumination
|
0.1Lux/F1.2 0Lux(IR On)
|
0.001Lux/F1.2
0Lux(IR on) |
||
|
Synchronous System
|
Internal Synchronization
|
|||
|
S/N Ratio
|
>48dB
|
>54dB
|
||
|
Electronic Shutter
|
1/50-1/60,000s(PAL)
1/60-1/60,000s(NTSC) |
|||
|
White Balance
|
ATW
|
|||
|
BLC
|
On
|
|||
|
AGC
|
Auto
|
|||
|
Gamma Adjusting
|
0.45
|
|||
|
Video Output
|
1.0Vp-p at 75Ω
|
|||
|
Lens
|
9-22mm Manual zoom Lens
|
|||
|
LED
|
￠10mm×12PCS
|
|||
|
IR Distance
|
80m
|
|||
|
Power Supply
|
DC 12V
|
|||
|
Working Temperature
|
-10°C~+50°C RH90% MAX
|
|||
|
Storage Temperature
|
-20°C~+60°C RH90% MAX
|
|||
|
Dimension(mm)
|
225mm×84mm×152mm
|
|||
|
Weight(g)
|
1050g
|
|||
