Specifications
|
Place of Origin: China (Mainland)
|
Brand Name: Sany
|
Model Number: SDCY80K6C
|
|
Type: Diesel
|
Power Souce: AC Motor
|
Rated Loading Capacity: 8000Kg
|
|
Max. Lifting Height: 16200mm
|
Min. Lifting Height: 3000mm
|
Fork Length: 1070mm
|
|
Fork Width: 120mm
|
Overall Dimensions: 6350mm*6038mm*9570mm
|
Weight: 32000Kg
|
|
Condition: New
|
Color: Red or Green
|
|
Packaging & Delivery
|
Packaging Detail:
|
Nude, Export standard specification,
|
|
Delivery Detail
|
35 days after receipt of deposit
|
Specifications
Telescopic 20'-40' spreader for empty containers
2 vertical twistlocks. Spreader weight 4700 kg
Designed lifting capacity 9000
2 vertical twistlocks. Spreader weight 4700 kg
Designed lifting capacity 9000
Lifting capacity: 8000 kg
Max. Lifting height: 16200 mm
Min. turning radius: 5480 mm
Wheelbase: 4000 mm
Dimension (length × width × height): 6350 × 6038× 9570 mm
Max. Lifting speed Rated load 500mm/s No load 600mm/s
Dead weight: 32000kg
Engine: VOLVO TWD 620VE (Sweden)-6 cylinders 6 litres
Power rating: 145 kW at 2300 rpm
Torque rating: 700 Nm at 1500 rpm
Transmission: DANA CLARK 13.7 HR32000 3 gears fwd/ 3 rev
Fully automatic transmission
Drive axle: Kessler D81 P L478 with wet disc brakes
Steer axle: SANY double acting steering cylinder
Spreader: SANY SDJ90
Tyres: 12.00×24 / 24 ply, Advance (Guizhou)
Colour: Standard
Car frame: Yellow
Mast: Red/ Black
STANDARD EQUIPMENT
Chassis
- Safe angled entrance
- Lifting eyes front/rear
- Towing pin
Body
- Steps with anti slip protection
- Rear view mirrors on each side
- Wheel nut protection
Driver’s Cab
- Electric controlled heater
- Fresh air and recirculation filter
- Step for roof access
- Instep handle
- Movable driver’s seat
- Armrest right hand side
- Wipers/washers on front, rear and roof pane
- Interval wipers on front, rear and roof pane
- Sliding window on both side
- Lockable doors (key)
- Door with air damper
- Inside rear view mirror
- Background button light
- Joystick for mast and attachment functions
Instrumentation
Hour meter, fuel gauge, RPM meter, temperature meters for engine, transmission. Meters for
oil pressure in engine and transmission. Indicator for direction, failure, high beam, parking brake,
safety system disconnected.
Manuals
User's manual, spare parts book, maintenance manual, safety manual, hydraulic & electrical
schematic diagram manual, maintenance manual and spare parts books for engine, transmission, drive
axle and spreader.
