Xiamen Xingyuanzhou Industrial Co., Ltd.
China Manufacturer with main products: Mucking Rock Loader, Crawler Mucking Loader, Tunnel Loader, Track Wheel Loader |
MS-120 crawler mucking loader( NEW MODEL)
| Supply Ability: | 600 Set/Sets per Year |
|---|---|
| Shipping: | 30days |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Fujian in China |
|---|---|
| Packaging Details: | One set per one HQ |
Specifications
Description of MS-120 Crawler Mucking Loader( big slope type):
The main act of MS-120 crawler mucking machine is controlled by the pilot valve. Operation is easy, peace and not impact. Capability is credible and maintain is facility. The machine has a fine humanism design because it has hydraulic system with wind cool, seat, cab, electric adding oil and has alarm system about journey beyond limit, oil temperature beyond height, oil route blocked, motor beyond load. These can alleviate the worker’s labor intensity. The machine is safe, easy and comfortable when the driver operates it. This crawler mucking loader is special designed for lane with big slope
The main act of MS-120 crawler mucking machine is controlled by the pilot valve. Operation is easy, peace and not impact. Capability is credible and maintain is facility. The machine has a fine humanism design because it has hydraulic system with wind cool, seat, cab, electric adding oil and has alarm system about journey beyond limit, oil temperature beyond height, oil route blocked, motor beyond load. These can alleviate the worker’s labor intensity. The machine is safe, easy and comfortable when the driver operates it. This crawler mucking loader is special designed for lane with big slope
TECHNICAL PARAMETER OF MS-120 CRAWLER MUCKING LOADER( BIG SLOPE TYPE)
|
Item
|
Unit
|
MS-120 Crawler Mucking Loader( Big Slope Type)
|
|||
|
Whole weight
|
kg
|
≈13200
|
|||
|
Loading capacity
|
m3/h
|
≈120
|
|||
|
|
|
Long arm
|
Short arm
|
||
|
Excavating width
|
mm
|
≤5900
|
≤5300
|
||
|
Excavating height
|
mm
|
≤2370
|
≤1970
|
||
|
Excavating distance( shovel)
|
mm
|
≤3390
|
≤3090
|
||
|
Excavating depth
|
mm
|
≤600
|
≤600
|
||
|
Unloading height
|
mm
|
1760~2100(changeable)
|
|||
|
Unloading distance
|
mm
|
3300( changeable)
|
|||
|
Travelling speed
|
m/s
|
0.7±5%
|
|||
|
Scraper chain speed
|
m/min
|
34
|
|||
|
Scraper transfer mechanism
|
|
Double chain double motor
|
|||
|
Climbing slope ability
|
°
|
≤35( hard floor)
|
|||
|
Suitable laneway slope
|
°
|
≤30
|
|||
|
Min.turning radius
|
m
|
≤6
|
|||
|
Rated working pressure
|
MPa
|
≤28
|
|||
|
Average grounding pressure
|
MPa
|
≤0.1
|
|||
|
Gradeability
|
mm
|
≥360
|
|||
|
Total power
|
mm
|
55
|
|||
|
Controlling method
|
kW
|
Hydraulic
|
|||
|
Crawler inner width
|
mm
|
1120
|
|||
|
Max.material dimension(W×H)
|
mm
|
620×740
|
|||
|
Max.arm slewing angle
|
°
|
±55
|
|||
|
Dimension
( working state)
|
Length
|
mm
|
≥9200
|
≥9000
|
|
|
Width
|
mm
|
1830
|
1830
|
||
|
Height
|
mm
|
≥2350
|
≥2350
|
||
|
Dimension
( stationary state)
|
Length
|
mm
|
≥10385
|
≥10185
|
|
|
Width
|
mm
|
1830
|
1830
|
||
|
Height
|
mm
|
≥2680
|
≥2680
|
||
The above technical data is only for reference.
