CCTV 8-channel DVR Kit

Supply Ability:	1,000 Piece/Pieces per Week
Shipping:	3-5days
Payment Terms:	T/T(Bank Transfer), Western Union, PayPal

Inquiry Now

GPS 4CH SD Mobile DVR Vehicle security system N...

Price:

Min. Order:2 Pieces
DVR Recorder / Video Recorder / Digital Recorde...

Price:100.00-200.00 USD/Piece

Min. Order:1 Piece
CIF Series DVR CSA-KT7316

Price:

Min. Order:
4 Inch DVR (TE-1004)

Price:50.00-52.00 USD/Piece

Min. Order:10 Pieces
H.264 8CH Standalone DVR

Price:

Min. Order:1 Piece
DV01-58 Wireless 8CH 5.8G DVR FPV RECORDER RECE...

Price:100.00-120.00 USD/Piece

Min. Order:1 Piece

Place of Origin:	Guangdong in China
Packaging Details:	standard carton box

Specifications

Features of CCTV 8-channel DVR kit

Ø Stand-Alone DVR, H.264 Compression

Ø High quality video Display:NTSC (720x480), PAL (720x576) real time display

Ø Multiple Recording/ Search Categories:Date/Time, Event, Manual, Schedule,
alarm, motion detection

Ø Real-time video recording :PAL,100/sec(1*D1 720x576;3*CIF 352×288),NTSC,120 frames/second(1*D 720x480;3*CIF 352×240)

Ø Pentaplex:Live, Record, Playback, Back-up and Network at the same time

Ø Backup: USB 2.0 and NET backup supported

Ø PTZ camera control in local and remote area

Technical Parameter of CCTV 8-channel DVR kit

Model Name	FL-DVR7604N
Compression Standard	H.264
Resolution	Preview resolution:704 x 576 ( PAL ) , 720 x 480 ( NTSC ) Playback resolution:1xD1 and 3 x CIF Frames:1F/S ~ 30F/S (Adjustable)
Hard Disk	1 SATA Hard Disk interface (Support Capacity no limited )
Video signal	PAL(625 line,50F/S)NTSC(525L/F,60F/S)
Video Input	4 channel, BNC , 1.0V p-p/75Ω
Composite Video Output	1 channel, BNC, 1.0V p-p/75Ω
VGA Interface	1 VGA, Resolution: 800x600/60HZ, 1024x768/60HZ 1024x1280/60Hz
Audio Input	1ch BNC
Audio Output	1ch BNC
Alarm Input	2 Channel
Alarm Output	1 Channel
Alarm Mode	Sensor Input, Motion Detection, Video Loss, Full Disk Space.
Network	Ethernet (10/100M ), LAN, DDNS, WAN and ADSL
Control Way	USB1.1 Mouse, Remote Control, Panel
Supports Cell phone	Symbian3.0 ,Symbian5.0, Windows mobile,Iphome
Serial port	RS485 x 1
Backup	USB2.0, Network
Bit Rate	5 Levels:150MB/H, 200MB/H ,250MB/H 300MB/H, 30～1000MB/H Self-defined
Password	Encrypted by 128-bit Numerical Digits with 2-Level Password Protection
Power Supply	DC12V /2.0-5.0A
Consumption	8W(Not Including Hard Disk)
Working Environment	Temperature: -5℃~+50℃; Humid:< 90% Storage Temperature:-20℃~+70℃;Humid:< 95%
Device Dimension	Mould:255mm(W)225mm(D) 44 mm(H),Package: 358mm(W)100mm(D)273mm(H)
Weight	N.W:1.2 KG G.W: 1.5KG
