| Packaging Details: | as per your requirements |
|---|
Specifications
FRP Pressure Vessel, FRP Vessel, Pressure Vessel, Pressure Tank
| NO. |
SIZE (inch) |
SIZE (mm) |
CALIBER (inch) |
VOLUME (M3) |
| 1 | 713 | φ180x335 | up: 2.5 inch | 0.02 |
| 2 | 717 | φ180x430 | up: 2.5 inch | 0.02 |
| 3 | 735 | φ180x905 | up: 2.5 inch | 0.04 |
| 4 | 744 | φ 180x1130 | up: 2.5 inch | 0.05 |
| 5 | 813 | φ205x335 | up: 2.5 inch | 0.02 |
| 6 | 817 | φ205x445 | up: 2.5inch | 0.02 |
| 7 | 835 | φ205x905 | up: 2.5 inch | 0.05 |
| 8 | 844 | φ205x1130 | up: 2.5 inch | 0.06 |
| 9 | 917 | φ230x430 | up: 2.5 inch | 0.03 |
| 10 | 935 | φ230x905 | up: 2.5 inch | 0.06 |
| 11 | 942 | φ230x1085 | up: 2.5 inch | 0.07 |
| 12 | 948 | φ230x1230 | up: 2.5inch | 0.08 |
| 13 | 1017 | φ255x445 | up: 2.5 inch | 0.04 |
| 14 | 1035 | φ255x905 | up: 2.5 inch | 0.07 |
| 15 | 1044 | φ255x1130 | up: 2.5 inch | 0.09 |
| 16 | 1054 | φ255x1390 | up: 2.5 inch | 0.11 |
| 17 | 1248 | φ300x1230 | up: 2.5inch | 0.13 |
| 18 | 1252 | φ300x1320 | up: 2.5 inch | 0.14 |
| 19 | 1265 | φ300x1650 | up: 2.5 inch | 0.18 |
| 20 | 1344 | φ330x1130 | up: 2.5 inch | 0.14 |
| 21 | 1354 | φ330x1390 | up: 2.5 inch | 0.17 |
| 22 | 1465 | φ350x1650 | up: 2.5 inch | 0.25 |
| 23 | 1465 | φ350x1650 | up: 4 inch | 0.25 |
| 24 | 1665 | φ400x1650 | up: 2.5 inch | 0.31 |
| 25 | 1665 | φ400x1650 | up: 4 inch | 0.31 |
| 26 | 1865 | φ450x1650 | up: 4 inch | 0.39 |
| 27 | 2162 | φ530x1575 | up: 4 inch | 0.51 |
| 28 | 2162 | φ530x1575 |
up: 4 inch bottom: 4 inch |
0.61 |
| 29 | 2069 | φ500×1750 | up: 4 inch | 0.47 |
| 30 | 2069 | φ500×1750 |
up: 4 inch bottom: 4 inch |
0.47 |
| 31 | 2472 | φ600×1850 | up: 4 inch | 0.71 |
| 32 | 2472 | φ600×1850 |
up: 4 inch bottom: 4 inch |
0.71 |
| 33 | 2477 | φ600×1950 | up: 4 inch | 0.75 |
| 34 | 2487 | φ600×2200 |
up: 4 inch bottom: inch |
0.85 |
| 35 | 3072 | φ750×1850 | up: 6 inch | 1.13 |
| 36 | 3072 | φ750×1850 |
up: 4 inch bottom: 4 inch |
1.13 |
| 37 | 3077 | φ750×1950 | up: 6 inch | 1.19 |
| 38 | 3087 | φ750×2200 |
up:4 inch bottom:6 cich |
1.34 |
| 39 | 3672 | φ900×1850 |
up: 4 inch bottom: 4 inch |
1.6 |
| 40 | 3694 | φ900×2400 | up: 6 | 2.08 |
| 41 | 3694 | φ900×2400 |
up: flange bottom: flange |
2.08 |
| 42 | 4072 | φ1000×1850 |
up: 4 inch bottom: 4 inch |
1.96 |
| 43 | 4094 | φ1000×2400 | up: 6 inch | 2.55 |
| 44 | 4094 | φ1000×2400 |
up: flange bottom: flange |
2.55 |
| 45 | 4872 | φ1200×1850 |
up: flange bottom: flange |
2.8 |
| 46 | 4894 | φ1200×2400 |
up: flange bottom: flange |
3.63 |
| 47 | 6094 | φ1500×2400 |
up: flange bottom: flange |
5.62 |
| 48 | 7294 | φ1800×2400 |
up: flange bottom: flange |
8.04 |
