LFQ-A Series Vertical Automatic Slitting Machine

Supply Ability:	2,000 Set/Sets per Year
Shipping:	15 to 25 days
Payment Terms:	T/T(Bank Transfer), Western Union

Inquiry Now

Related products from verified members

Big Factory Bone Saw Cutting Saw

Price:3,333.00-4,000.00 USD/Set

Min. Order:2 Sets
Automatic shear machine width=1300

Price:1.00-2.00 USD/Roll

Min. Order:1 Roll
CNC QC11K Hydraulic Guillotine Shear

Price:29,999.00-999,999.00 USD/Set

Min. Order:1 Set
500w Fiber Laser Cutting Machine for Metal Bill...

Price:95,000.00-100,000.00 USD/Set

Min. Order:1 Set
Stone Cutting Saw

Price:

Min. Order:
NC Pipe Cutting & Beveling Machine

Price:4000.00-6000.00 USD/Set

Min. Order:1 Set

Product Details

Place of Origin:	Zhejiang in China
Packaging Details:	WOODEN CASE

Specifications

Characteristics:
This machine is suitable for slitting and rewinding such as BOPP, OPP, PET, CPP, CPE, PVC, PE, adhesive tape, aluminum foil, web, coated paper, cellophane paper, silicone paper, centrifugal paper, self-adhesive paper, kraft paper, composite paper, pellicle and non-woven fabrics etc. It should depend on different requirements to slit roll material.

Advantages:
This machine has the best performance of track, automatic rectify, tension control, wind counting and counting down etc. The whole machine adopts micro-computer to control, automatic slitting, reasonable structure, complete function, easy to operate, stable and reliable operation.

Main Technical Parameter:

Model	LFQ-700A	LFQ-1100A	LFQ-1300A
Max. Roll width	700mm	1100mm	1300mm
Max. Roll Diameter	Φ600mm	Φ600mm	Φ600mm
Roll Width	20-600mm	20-1000mm	20-1200mm
Slitting Speed	5-160m/min	5-160m/min	5-160m/min
Tolerance of EPC	<±0.3mm	<±0.3mm	<±0.3mm
Total Power	3kw	4kw	7kw
Weight of Machine	1300kg	1800kg	2800kg
Overall Dimension	2000×1110×1400mm	2400×1110×1400mm	2600×1110×1400mm
