| Place of Origin: | Tianjin in China |
|---|
Specifications
The Lattice Girder Welding Machine is of good quality and reasonable price :
Products Introduction : Automatic processing line combine with pay-off, straightening system, bending system, auto welding, measured cut and production transfer, widely used in building construction ( steel bar truss deck ), high-speed rail ( double-block sleeper ) construction and other fields.
CHARACTERISTIC
1, Stepping system control by CNC servomotor.
2, Automatic pay-off control system.
3, User friendly inerface, easy operation.
4, Forming ( Zig-Zag ) device, high precision and stability.
5, All electrical components are supplied by SIEMENS and YASKAWA.
6, SCR unit features low power, low volume and high reliability.
7, Girder evacuation & automatic stacking unit.
8, Optimize malfunction diagnose warning system.
9, Diagonal forming ( Zig-Zag ) device (patent).
10, Perfect produce manage system.
11, Electricity components used of SIMENS and YASKAWA.
12, Control systems: SIEMENS, MITSUBISHI, PANASONIC.
TECHNICAL DATA
|
Model
|
SJL320A
|
SJL100A
|
|
Installed power welding(KVA)
|
4*175
|
4*175
|
|
Installed power for rest of machine(kw)
|
80
|
80
|
|
Installed voltage(v)
|
380V 50Hz
|
380V 50Hz
|
|
System voltage(v)
|
380V 50Hz
|
380V 50Hz
|
|
Control voltage(v)
|
24
|
24
|
|
Diagonal wire diameter (mm)
|
5-8
|
5-8
|
|
Longthitudinal wire diameter(upper)(mm)
|
8-12
|
8-12
|
|
Longthitudinal wire diameter(lower)(mm)
|
8-12
|
8-12
|
|
Girder height (mm)
|
50-320(can be ordered)
|
50-100(can be ordered)
|
|
Girder internal base width (mm)
|
50-150(can be ordered)
|
50-150(can be ordered)
|
|
Girder length(mm)
|
200-1200
|
200-1200
|
|
Diagonal spacing(mm)
|
190-300(can be ordered)
|
190-300(can be ordered)
|
|
Power cable cross-sectional aress
|
1*185mm²+1*195mm²
|
1*185mm²+1*195mm²
|
|
Overall length(mm)
|
42000
|
42000
|
|
Produvction rate(m/min)
|
12-15
|
12-15
|
