Bicyle Multi-Function Impact Tester (HD-1048)
| Supply Ability: | 60 Set/Sets per Month |
|---|---|
| Payment Terms: | L/C, T/T(Bank Transfer), Western Union |
Related products from verified members
| Place of Origin: | Guangdong in China |
|---|---|
| Packaging Details: | strong wooden cases |
Specifications
Detailed Product Description
multi-function impact tester
1.Anticollision device to ensure the test precision
2.Impact height:Max. 1500mm (adjustable )
1.Anticollision device to ensure the test precision
2.Impact height:Max. 1500mm (adjustable )
multi-function impact tester
multi-function impact tester applies to impact test of bike's components and parts, it can do various impact test such as front fork falling weight impact test, front fork dropping impact test, pedals falling weight impact test ( horizontal, vertical or diagonally), handle bar impact test, crank vertical impact test, etc. It is modularization designed with simple and safe operation, the specification can meet the requirements of various standards.
Main technical parameters
Impact height Max. 1500mm (adjustable according to the test requirements)
Height indication ruler Zero mark can be adjusted according to the height of molds or specimen
Impact mass (kg) 5~40kg, modular alternating, equip according to the requirement
Work bench size(W× H) 60CM× 180CM
Guide for up and down Linear bearing and SUJ slide way, min. resistance coefficient
Falling weight trigger Electromagnetic on-off device, double insurance of falling, safe and durable
Falling weight modularization Alternate the type of falling weight according to test specification, convenient and economical
Anticollision device To ensure the test precision
Modulation control-box Adjust the height and frame foundation
Arresting gear Protection switch of rising upper limit and falling lower limit, locating device
structure Safe Preventer plate, baking finish and toning, double TFC35
power Three phase, 220V, 50/60HZ or designated
Outside Dimension (L× W× H) 100× 180× 240 cm
Weight 160kg
Design criteria ISO, BS/DIN/NF, CPSC/CSA, JIS/JBMS/BA, AS/NES, GB/QB/CNS
