Shanghai Longyang Machinery Factory
China Manufacturer with main products: Crusher, Jaw Crusher, Cone Crusher, Impact Crusher, Rounding Vibrating Screen, Vibrating Feeder, Spring Cone Crusher, Hydraulic Cone Crusher |
15th
Shanghai LY Stone Cone Crusher
| FOB Price: | 1,000.00 - 90,000.00 USD/Set |
|---|---|
| Supply Ability: | 40 Set/Sets per Month |
| Shipping: | 7-25days |
| Payment Terms: | L/C, T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shanghai in China |
| Packaging Details: | cone crusher Standard container, in bulk, nude pack, packed as customer's requirement. |
Specifications
Detailed description about LY Stone Cone Crusher
LY Stone Cone Crusher, which could raising efficiency in rock-crushing. To adopt the technics of with concave and mantle after machining process to connect with cone surface to instead the anciently complicated technics, fully ensure the safely and stability during operation. And it is applicable to break various ores and rocks with high hardness, low running cost and widely used in metallurgical mining, architectural, road & railway building, etc.
PYG superfine gyradisc type cone crusher is suitable for produce machine-made sand and metal ore.
Technical Parameters
|
Spring Cone Crusher Model
|
Diameter of Bottom End of Conical Crushing Head (mm)
|
Max. Feed Edge (mm)
|
Discharge Opening Width (mm)
|
Processing Capacity (t/h)
|
Motor Power (kw)
|
Weight (t)
|
Overall Dimensions L*W*H(mm)
|
|
PYB-900TC
|
900
|
150
|
25-38
|
115-160
|
75
|
11.86
|
2430*1770*2200
|
|
PYB-900C
|
900
|
150
|
13-38
|
60-160
|
75
|
11.85
|
2430*1770*2200
|
|
PYB-900X
|
900
|
85
|
9-22
|
45-90
|
75
|
11.93
|
2430*1770*2200
|
|
PYD-900C
|
900
|
85
|
3-19
|
60-130
|
75
|
12.15
|
2430*1770*2200
|
|
PYB-900Z
|
900
|
65
|
3-16
|
25-100
|
75
|
12.13
|
2430*1770*2200
|
|
PYB-900X
|
900
|
35
|
3-13
|
25-90
|
75
|
12.05
|
2430*1770*2200
|
|
PYB-1300TC
|
1300
|
220
|
25-50
|
230-350
|
132-185
|
22.5
|
2890*2250*2710
|
|
PYB-1300C
|
1300
|
205
|
19-50
|
170-340
|
132-185
|
22.5
|
2890*2250*2710
|
|
PYB-1300Z
|
1300
|
175
|
16-38
|
130-250
|
132-185
|
22.5
|
2890*2250*2710
|
|
PYB-1300X
|
1300
|
115
|
13-30
|
110-180
|
132-185
|
22.5
|
2890*2250*2710
|
|
PYD-1300TC
|
1300
|
110
|
16-25
|
205-235
|
132-185
|
22.6
|
2890*2250*2710
|
|
PYD-1300C
|
1300
|
88
|
8-25
|
108-225
|
132-185
|
22.6
|
2890*2250*2710
|
|
PYD-1300Z
|
1300
|
75
|
6-16
|
82-160
|
132-185
|
22.6
|
2890*2250*2710
|
|
PYD-1300X
|
1300
|
54
|
3-16
|
36-160
|
132-185
|
22.6
|
2890*2250*2710
|
|
PYB-1600TC
|
1600
|
310
|
38-63
|
430-630
|
250
|
43.3
|
3630*3270*3230
|
|
PYB-1600C
|
1600
|
225
|
25-63
|
290-630
|
250
|
43.3
|
3630*3270*3230
|
|
PYB-1600Z
|
1600
|
205
|
22-50
|
250-415
|
250
|
43.3
|
3630*3270*3230
|
|
PYB-1600X
|
1600
|
175
|
16-36
|
180-325
|
250
|
43.3
|
3630*3270*3230
|
|
PYD-1600TC
|
1600
|
110
|
13-25
|
250-335
|
250
|
44
|
3630*3270*3230
|
|
PYD-1600C
|
1600
|
110
|
10-25
|
190-335
|
250
|
44
|
3630*3270*3230
|
|
PYD-1600Z
|
1600
|
75
|
6-19
|
135-280
|
250
|
44
|
3630*3270*3230
|
|
PYD-1600X
|
1600
|
60
|
5-13
|
90-208
|
250
|
44
|
3630*3270*3230
|
|
PYB-2100TC
|
2100
|
390
|
38-64
|
1250-1940
|
400
|
90
|
4613*3302*4638
|
|
PYB-2100C
|
2100
|
315
|
31-64
|
1125-1810
|
400
|
90
|
4613*3302*4638
|
|
PYB-2100Z
|
2100
|
280
|
25-51
|
860-1420
|
400
|
90
|
4613*3302*4638
|
|
PYB-2100X
|
2100
|
235
|
19-38
|
540-1035
|
400
|
90
|
4613*3302*4638
|
|
PYD-2100TC
|
2100
|
172
|
16-25
|
580-740
|
400
|
90
|
4613*3302*4638
|
|
PYD-2100C
|
2100
|
150
|
13-25
|
515-680
|
400
|
90
|
4613*3302*4638
|
|
PYD-2100Z
|
2100
|
113
|
10-19
|
405-580
|
400
|
90
|
4613*3302*4638
|
|
PYD-2100X
|
2100
|
89
|
5-16
|
218-460
|
400
|
90
|
4613*3302*4638
|
|
PYG-1200
|
1200
|
50
|
10-20
|
80-120
|
185
|
24
|
2880*2140*2800
|
TC-Extra coarse type; C-Coarse type; Z-Medium type; X-Fine type
LY production of spring cone crusher, cone crusher, stone crusher have quality assurance.
