Super Silent Diesel Generator Set

Super Silent Diesel Generator Set
Silent Generator Set Model No. GFS


** Rating Range **


- 10-2000kVA, 50/60Hz, Noise<70dB/7m, Three or Single Phase
- Diesel engine available at international brands (such as Cummins, Deutz, Perkins, MTU, etc.) and Chinese brands
- Alternator available at international brands (such as Stamford, Marathon, Leroy Somer, etc.) and Chinese brands (especially our own-brand top-performance alternators)
- Controller available at international brands (such as Deepsea, ComAp, etc.) and Chinese brands


** Electrical performance **


- Steady voltage regulation:
 For standard type: within ±1%
 For digital type: within ±0.5%
- Transient voltage regulation:
 For standard type: -15%~+20%  (best in China)
 For phase-compound-excitation type: -12%~+15%  (best in the world)
- Transient voltage recovery time:
 For standard type: ≤1s  (best in China)
 For phase-compound-excitation type: ≤0.5s  (best in the world)
- Steady frequency regulation: within ±3%
- Transient frequency regulation: within ±10%
- Transient frequency recovery time: ≤3s
- Voltage adjustment range: (95~105)%Un
- Voltage fluctuation (tolerance): within ±0.5%
- Voltage waveform distortion (harmonic contents): ≤2%  (best in China)
- Total voltage unbalance under unbalanced loads: ≤3%  (best in China)
- Insulation: Class H


** Product Features **


- Worldwide advanced designs, licensed with national technical patents
- Super low operation noise, obtained through high-efficiency fire-resistant acoustic materials and multiple acoustic attenuation measures
- Wide rating range
- All products are designed in compliance with IEC, ISO & most other international standards, and are manufactured in ISO9001 certified & military certified facilities
- Compact size & popular outlines
- Competitive pricing


** Predominant Advantages **


- Excellent electrical performances in all aspects
- Excellent output waveform at lowest harmonic distortion, suitable for all kinds of important applications
- Ultra-low operation temperature rise to ensure high reliability and long service life
- Unique ventilation structure to improve cooling effect by at least 30%
- Unique Compound Excitation Technology to offer best dynamic performance (i.e. quicker voltage recovery and smaller voltage fluctuation at any sudden loading change)
- Unique Double Remanence Technology to offer complete reliability in self-excited voltage buildup
- Solid fully encapsulated AVR and rectifier to resist moisture, vibration, salt fog and chemical corrosions
- Precise voltage regulation, with low-speed protection
- Popular outline, compact size, high reliability and long service life
