Jinan Haoyu Woodworking Machinery Co., Ltd.
China Manufacturer with main products: Vacuum Membrane Press, Woodworking CNC Router, Profile Wrapping Machine, Edge Banding Machine, Overhead Router, Panel Saw, Wide Belt Sander,... |
woodworking vacuum press
| FOB Price: | 3,500.00 - 9,000.00 USD/Set |
|---|---|
| Supply Ability: | 200 Set/Sets per Month |
| Shipping: | 20days |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Shandong in China |
|---|---|
| Packaging Details: | wooden package |
Specifications
Detailed Product Description
woodworking vacuum press
mainly used for press
PVC or veneer on curved surface,
eg: interior door,
cabinet door,furniture,etc
woodworking vacuum press
PVC or veneer on curved surface,
eg: interior door,
cabinet door,furniture,etc
woodworking vacuum press
Applicable covering material: PVC,natural veneer, transfer
Sphere of application:
it is intended for laminate doors, kitchen and furniture facades, different furniture units with PVC films and veneer, with the help of heat and vacuum technique system. As result you will receive product with long life use and the same time with elegant and inclusive surface.It is applicable to cover plate type furniture (sound box, cabinet, door), decorative dado and all kinds of baroque decorative surfaces with PVC films and wood skins and hot stamping foils.
Technical parameters:
1) External dimensions: 9,000 x 1,800 x 1,300mm
2) Worktable dimensions: 2,550 x 1,150 (1,300) x 50mm
3) Max. processing height: 80mm
4) PVC thickness:0.1-0.35mm;
5)Max vacuum press:-0.1Mpa;
6) Total power: 20kW
7) Actual power:5kW
8)Total weight: 2,500kg
Features:
1. This machine has 2 work table,The electronic part is fully automatic and digitalized control. The components are produced by famous domestic enterprises with good quality. The temperature is controlled by computer chips so that the heating speed is adjustable and the temperature can be perfectly managed.
2. Use infrared heating system and high quality heat preservation material, which can ensure even heating and energy saving.
3. This machine uses integrated movement electromotor. It produces less noise and seldom breaks down.
4. This machine uses top 2X series vacuum pump. It is stable and reliable and the maintenance work is simple. (You can also adopt for German-made vacuum pump, which is strong and tough).
5. Large volume vacuu
Sphere of application:
it is intended for laminate doors, kitchen and furniture facades, different furniture units with PVC films and veneer, with the help of heat and vacuum technique system. As result you will receive product with long life use and the same time with elegant and inclusive surface.It is applicable to cover plate type furniture (sound box, cabinet, door), decorative dado and all kinds of baroque decorative surfaces with PVC films and wood skins and hot stamping foils.
Technical parameters:
1) External dimensions: 9,000 x 1,800 x 1,300mm
2) Worktable dimensions: 2,550 x 1,150 (1,300) x 50mm
3) Max. processing height: 80mm
4) PVC thickness:0.1-0.35mm;
5)Max vacuum press:-0.1Mpa;
6) Total power: 20kW
7) Actual power:5kW
8)Total weight: 2,500kg
Features:
1. This machine has 2 work table,The electronic part is fully automatic and digitalized control. The components are produced by famous domestic enterprises with good quality. The temperature is controlled by computer chips so that the heating speed is adjustable and the temperature can be perfectly managed.
2. Use infrared heating system and high quality heat preservation material, which can ensure even heating and energy saving.
3. This machine uses integrated movement electromotor. It produces less noise and seldom breaks down.
4. This machine uses top 2X series vacuum pump. It is stable and reliable and the maintenance work is simple. (You can also adopt for German-made vacuum pump, which is strong and tough).
5. Large volume vacuu
