Shandong UT Trailer Parts Co., Ltd.
China Manufacturer with main products: Semitrailer, Trailer, Semitrailer Parts |
Related products from verified members
-
Price:35,000.00-45,000.00 USD/SetMin. Order:1 Set -
Price:35,000.00-38,000.00 USD/UnitMin. Order:1 Unit
| Packaging Details: | in container |
|---|
Specifications
SPECIFICATION
GENERAL
LENGTH x WIDTH x HEIGHT According to axle number and volume requirement
TANK INSIDE VOLUME 30 – 50 CBM
PAY LOAD 24 - 60 tons
RUNNING GEAR
SUSPENSION Air suspension or Mechanical (multi leaf spring) Suspension with equalizer beam
DRUMS Outboard mounted, hub piloted cast steel
HUBS Cast steel 8 or 10 studs
WHEELS Steel disc
TIRES Nylon, radial or tubeless tires, famous brand, include 1 spare tire
AXLES 2, 3 or 4 axle, BPW, SAF, FUWA, LT or ANQIAO brand, 12 – 20 tons payload per axle
BRAKES Dual line brake system, non-asbestos, includes automatic slack adjusters
ABS SYSTEM Available upon request
VALVE WABCO or SEALAND emergency relay valve
BRAKE CHAMBER TGL or FUWA 30/30 chamber, air-actuated
UNDERFRAME
MAIN BEAM I shape, Mild Alloy (Q345B, tensile strength 34.5kg/mm^2) by Automatic submerged arc welding. Top Flange 16mm, Button Flange 16mm;Middle Flange 6mm thickness
CROSS BEAM U shape, Mild Alloy Q345B, tensile strength 34.5kg/m^2
KING PIN JOST or FUWA brand, 2", 2.5" or 3.5", welded or bolted in type
LANDING GEAR JOST, FUWA, Baohua Holland brand, Static capacity 25 Tons
MUD FLAPS Anti-sail, mounted on sliding tandem
BUMPER Heavy duty bumper at the end
APPENDIX 1 toolbox
2 Spare tyre carriers
2 Units of Manhole Seal
2" flexible hose
TANK BODY
MATERIAL Q235A Plate
SHAPE V shape, elliptic shape or cylinder shape structure
MANHOLE 2 sets, compact by rotating
END PLATE Q235A Plate, ball shape
AIR COMPACT SYSTEM (FOR OPTION)
AIR COMPRESSOR Chinese famous brand
DISEL ENGINE Chinese famous brand
FILTRATION AND PRESSUE CONTROL At output of air compressor
AIR ROUTE SYSTEM Main hole, check valve, safe valve, gauge
Guard System
GUARD ON TOP OF TANK Chequered plate
SIDE GUARD Cross bar structure
REAR BUTTON GUARD Fixed type
Discharge System
DISCHARGE MEANS Seamless steel tube at button of funnel and through top of axle
QUADRATIC BLOW Same direction as discharge tube, with ball valve and check valve DISCHARGE VALVE Disc valve fixed inside middle of rear guard
PIPELINE CLEANING EQUIPMENT At beginning of discharge tube
TANK CLEANING EQUIPMENT Rubber flexible hose
ELECTRICAL & PAINT
LIGHTS, REFLECTORS Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
WIRING 24V, 6 lines
AIR/ELEC. CONNECTOR ISO standard air connector,
24V 7-pin plug socket
PAINT Sand blasting before painting
1 coat of anticorrosive primer
2 coats of finish urethane paint
Color as per request
