| Place of Origin: | Beijing in China |
|---|---|
| Packaging Details: | Exporting package |
Specifications
Pressure Gauge HX601D
DESCRIPTION
Pressure Gauge HX601D precision digital pressure gauge (Low Power Consumption) adopts micropower components,with Built-in silicon sensor technology.
Dry cell & the once-off lithium battery powered, which could work for 1 year continually. Fully temperature compensation assured the accuracy.
5 digit large LCD with backlight.
It is different from mechanical pressure gauge,very rugged,new aluminum case, easy to operate.
FEATURES
- High Accuracy, Low Power Consumption, Small
- 5 Digit big LCD
- Various Pressure Units selectable
- Zero Point, Full Scale calibration function
- Adopt the special software treatment technology, unnecessary to preheat
- RS232 Communication port, which could communicate with the computer conveniently.
- Temperature compensating range: (0~50)°C
- Working environment temperature(0-50) °C Humidity ≤85%
- With the EEPROM NVM, It has the power off data losing protection function
- High intelligentization, Number compensation, Number Communication and Number calibration.
- Bottom conncetion:stainless steel
- cover:aluminum
Functions
Pressure Gauge HX601D Precision digital Pressure gauge HX601 can be widely used in power,petrol,chemical,metallurgy,metering industry,and so on.
provides pressure measurement for calibrating pressure(different pressure),precision(general) pressure gauges,sphygmomanometers,pressure-reducing valves and other pressure instrument.
Specifications
|
Pressure range
|
(-1~0)bar, (0~600)bar
|
|
Accuracy
|
±0.05%F.S , ±0.1%F.S, ±0.2%F.S
|
|
Temperature compensation range
|
(0~50) ºC
|
|
9 Engineering units
|
MPa, Pa, psi, kgf, bar, mbar, mmH2O, mmHg, kPa
|
|
Connection
|
M20×1.5male/ 1/4NPTmale
|
|
Communication
|
RS232
|
|
Dimensions
|
134mm×93.15mm×40.5mm
|
|
Display
|
58mm×26mm
|
|
Weight
|
0.5kg
|
|
CE &EX approved
|
|
|
Provide test report by our company
|
|
