Eastern Electromechanics Industrial Limited
China Manufacturer with main products: AC Servo Motor, AC/DC Geared Motor, Stepper Motor, CNC Spindle |
Electric Motor
| FOB Price: | 425.00 - 440.00 USD/Set |
|---|---|
| Supply Ability: | 8,500 Set/Sets per Month |
| Shipping: | Around 15 days after payment |
| Payment Terms: | T/T(Bank Transfer), Western Union |
Related products from verified members
| Place of Origin: | Guangdong in China |
|---|---|
| Packaging Details: | Standared export package |
Specifications
Detail spec of the AC servo motor :
Item: MT 80Series
Specifications
|
Motor model
|
80MT-M01330
|
80MT-M02430
|
80MT-M03520
|
80MT-M04025
|
||||||||||||||||||||
|
Rated power(KW)
|
0.4
|
0.75
|
0.73
|
1.0
|
||||||||||||||||||||
|
Rated voltage(V)
|
220
|
220
|
220
|
220
|
||||||||||||||||||||
|
Rated current(A)
|
2
|
3
|
3
|
4.4
|
||||||||||||||||||||
|
Rated speed(rpm)
|
3000
|
3000
|
2000
|
2500
|
||||||||||||||||||||
|
Holding torque(N.m)
|
1.27
|
2.39
|
3.5
|
4
|
||||||||||||||||||||
|
Peak torque(N.m)
|
3.8
|
7.1
|
10.5
|
12
|
||||||||||||||||||||
|
Peak current(A)
|
6
|
9
|
9
|
13.2
|
||||||||||||||||||||
|
Voltage conMTant
(V/krpm)
|
40
|
48
|
71
|
56
|
||||||||||||||||||||
|
Torque coefficient
(N.m/A)
|
0.64
|
0.8
|
1.17
|
0.9
|
||||||||||||||||||||
|
Rotor inertia(Kg.㎡)
|
1.32×10-4
|
2.4×10-4
|
3×10-4
|
3.5×10-4
|
||||||||||||||||||||
|
Phase ResiMTance(Ω)
|
4.44
|
2.88
|
3.65
|
1.83
|
||||||||||||||||||||
|
Phase Inductance
(mH)
|
7.93
|
6.4
|
8.8
|
4.72
|
||||||||||||||||||||
|
Machanical time-conMTant
(Ms)
|
1.66
|
2.22
|
2.4
|
2.58
|
||||||||||||||||||||
|
Weight(Kg)
|
1.78
|
2.86
|
3.7
|
3.8
|
||||||||||||||||||||
|
Encoder line number
(PPR)
|
2500
|
|||||||||||||||||||||||
|
Insulation class
|
Class B(130℃)
|
|||||||||||||||||||||||
|
Safety class
|
IP65
|
|||||||||||||||||||||||
|
The operating
of Evironmental Conditions
|
Temperature: -20℃ ～ +50 ℃
Humidity: Below 90%RH No dewing
|
|||||||||||||||||||||||
|
Motor winding
plue
|
Winding lead wire
|
U(red)
|
V(yellow)
|
W(blue)
|
PE(yellow, green/black)
|
|||||||||||||||||||
|
Plug serial numberr
|
1
|
2
|
3
|
4
|
||||||||||||||||||||
|
Encoder plug
|
Signal lead wire
|
5V
|
0V
|
B+
|
Z-
|
U+
|
Z+
|
U-
|
A+
|
V+
|
W+
|
V-
|
A-
|
B-
|
W-
|
PE
|
||||||||
|
Plug serial number
|
2
|
3
|
4
|
5
|
6
|
7
|
8
|
9
|
10
|
11
|
12
|
13
|
14
|
15
|
1
|
|||||||||
|
Color
|
red
|
black
|
green
|
yellow
black
|
brown
|
yellow
|
brown
black
|
blue
|
grey
|
white
|
grey
black
|
blue
black
|
green
black
|
White
black
|
|
|||||||||
