End Suction Centrifugal Water Pump for Irrigation Or Fire Fighting

Supply Ability:	600 Set(s) per Month
Shipping:	within 20days after your deposit. CNF from Xingang port to your port by sea
Payment Terms:	L/C, T/T, Western Union, MoneyGram

Inquiry Now

Product Details

Export Markets:	South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Western Europe
Place of Origin:	Hebei in China
Packaging Details:	wooden case

Quick Details

Pressure: High Pressure
Standard or Nonstandard: Standard
Power: Electric
Structure: Single-stage Pump
Brand Name: ZIDONG
Model Number: IS
structure: horizontal single stage
wet parts: cast iron
OEM: welcome

Specifications

Centrifugal water pump for irrigation or fire fighting

Specifications

1.Type IS water pump producer
2.10 years pump factory
3.Own casting workshop
4.OEM Service
5.ISO, CE

Type IS water pump:

Technical Parameter&Working condition

A) Material: SS304, SS316L ect
B) Caliber: DN50-DN200mm
C) Flow: 6.3-400m3/hr
D) Head: 5-125m
E) Rotate speed: 3500r/min; 2900 r/min; 1450 r/min
F) Work temperature: 80C
G) Viscosity: 150mm2/s
H) Pressure: 1.6Mpa
I) Motor power: 0.75-90KW

Production Overview:

IS series single stage single suction horizontal centrifugal water pump is provided in accordance with international standards IS02858
Performance and size of the design, its technical standards are to international standards, reached to the international advanced level.
It's china's promotion of energy-saving pumps.

Meaning of type(for example:IS65-40-250A)

65 is inlet diamter (mm)
40 is outlet diameter(mm)
250 is impeller diameter(mm)
A means the first cut on impeller

Main Structure:

the series of single-stage centrifugal pump are designed according to the properties and dimension of international standard ISO2858.

the pump casing and cover make up of the operating room of pump.the impeller,shaft and ball bearing make up of the rotor parts of
Pump.the hanger supports the rotor parts of pump.the axial and radial force of pump is borne by the ball bearing.the axial sealing
of pump is made up of packing gland(9),packing(10)and packing ring (8) (mechanical sealing also can be used),which to avoid gas
to enter and greatly leak.
the shaft sleeve is installed on the position of packing to protect the shaft to avoid the wear of shaft.O sealing ring is installed
between the shaft and sleeve to avoid gas to enter and leak along the surface of shaft.
the front and back of impeller mostly has sealing ring to balance the axial force,and there is balancing hole on the back cover plate
of impeller.If the axial force is not too big,there no sealing ring and balancing hote on the back of impeller.
the elastec coupler and motor is connected to drive.the revolving of pump is clockwise when being viewed from the end of driving.
the pump applies to the area of 50HZ or 60HZ power source.

Key words:
Water pump,irrigation water pump,fire fighting water pump,diesel water pump.
Slurry pump,china,hebei,shijiazhuang sewater pump,centrifugal pump

If any needs or questions,you are welcome to tell us.
We will give professional reply to u within 12hours.
