Qingzhou Shuangxin Trading Co., Ltd.
China Manufacturer with main products: Wheel Loader, Mini Loader, Small Loader, Front Loader, Mini Wheel Loader, Small Wheel Loader, Front End Loader, Shovel Loader |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | 1set/20 Gp 3 set/40HQ |
Specifications
china 915 mini wheel loader with ce and europe III(quick hitch couple)
1)ADJUSTABLE AND LUXURY SEAT
2)PILOT CONTROL(JOYSTICK)
1)ADJUSTABLE AND LUXURY SEAT
2)PILOT CONTROL(JOYSTICK)
Specifications of ZL 15F wheel loader
1.0 Engine Details
(1) Model: Xinchai 498BT
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g /kw.h
1.0 Engine Details
(1) Model: Xinchai 498BT
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g /kw.h
2.0 Transmission System
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
3.0 Bucket
(1) Bucket Capacity: 0.7 m3
(2) Bucket width: 550mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 36.8KN
(5) Rated Load: 1500kg
(6) Operating Weight: 3500kg
(1) Bucket Capacity: 0.7 m3
(2) Bucket width: 550mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 36.8KN
(5) Rated Load: 1500kg
(6) Operating Weight: 3500kg
4.0 Overall Dimensions
(1) Overall Length (Bucket on ground position): 5200mm
(2) Overall Height
(a) Ground to Cab Top: 2650mm
(b) Dumping Height: 2650mm
(c) Min. Base to the Ground: 260mm
(3) Overall Width: 1730mm
(1) Overall Length (Bucket on ground position): 5200mm
(2) Overall Height
(a) Ground to Cab Top: 2650mm
(b) Dumping Height: 2650mm
(c) Min. Base to the Ground: 260mm
(3) Overall Width: 1730mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4500mm
(3) Driving System: Hydraulic converter
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4500mm
(3) Driving System: Hydraulic converter
6.0 Brake System
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
7.0 Tyre
(1) Model:12-16.5
(1) Model:12-16.5
Service Guarantee
-
Free Service Charge
ECVV doesn't charge any service fee to Buyers for buying this product.
-
ECVV Supply
ECVV is responsible for supply, and provides product quality inspection, fund supervision and supply chain services.
-
Product Quality Commitment
ECVV China Sourcing Agent will assess the reputation and supply ability of the factory and conduct field trips to select the high-quality Chinese factories for buyers.
-
Deposit Service Commitments
In order to improve the quality of service, ECVV will charge for a 100CNY deposit for the agent purchasing order, and the deposit will be part of subsequent purchasing costs.
After paying a deposit, if the purchasing order is not completed because of unsatisfied ECVV services, ECVV will refund your deposit.
