Shenzhen J&D Packing Equipment Co., Ltd.
China Manufacturer with main products: Filling Machine, Packing Machine, Bottle Blown Molding Machine, Printing Machine |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Specifications
1. Automatic break protection for power leakage and short circuit;2.Under-pressure protection: when incoming air's pressure is ≦0.5MPa, the equipment will be? automatically stopped;3. Water-shortage protection: when the level of the water tank is lower than that of the liquid switch, the equipment will be automatically stopped.
Remarks:We can add other functions as customer's requirements like:hot tank heating washing, bottle external washing, cap washing , capacity note and man-machinecontrol.
Remarks:We can add other functions as customer's requirements like:hot tank heating washing, bottle external washing, cap washing , capacity note and man-machinecontrol.
Information:
|
Model
|
XG100
|
XG100
|
|
Output
|
450BPH
|
600BPH
|
|
Voltage
|
AC220V/380V±5% 50HZ/60HZ
|
|
|
Rated Power
|
11.1KW
|
14.8KW
|
|
Washing heads
|
3x7
|
4x9
|
|
Filling heads
|
3x1
|
4x1
|
|
Capping heads
|
1x1
|
1x1
|
|
Bottle size
|
Ф270×490×Ф56 mm
|
|
|
Cap size
|
Ф58×40(Tail: L×W=18×7.5) mm
|
|
|
Air pressure
|
0.5～0.6MPa
|
0.5～0.6MPa
|
|
N.W.
|
950Kg
|
1450Kg
|
|
Overall Dimension(MM)
|
4390×1100×1760
3000×800×1760
|
4710×1520×1760
3220×800×1760
|
