LBSROLL Machinery (Shanghai) Co., Ltd.
China Manufacturer with main products: Stretch Wrpping Machine, Conveyor Roller |
Specifications
Roller Specs:
Max Work Speed:
2m/s
Max Loading Capacity:
Up to 5000N
Tube Materials and Finishes:
Carbon Steel, Galvanized Steel,Hard Chromed Steel, Decorated Chromed Steel, Stainless SteelAluminum Other Options Available on Request
Cover Options:Black Rubber( 3-5mm thick) Urethane Sleeves High Density Polyethlene (HDPE) Polyvinyl Chloride (PVC)
Tube Sizes:
According to customers' requirements
Shafts:
Tapped ends, pin retained and other configurations available upon request Roller shafts are spring loaded on both ends for easy installation and removal.End deburring is standard.
Shaft Materials:
Carbon Steel
Stainless Steel
Aluminum
Zinc and Nickel Plating Available
Shaft End Options:
Hexagonal, Round
Female or Male Threaded
Drilled and Tapped
Drilled Holes.
Springs:
Dual/Single spring loaded with shaft depressing to the hub of the bearing
Bearings & Bushings:
Commercial Grade
Plated Steel/Metal Housings
These bearings are manufactured utilizing hardened steel balls and raceways.
The outer raceway is either stamped or machined and lubricated with light oil.
Grease packed bearings may be ordered for driven systems
Plated Steel/Plastic Housings
Designed for light to moderate loads, The plastic housed bearings have hardened steel balls and Stamped or machined inner and outer raceways.
They are available with light oil or grease lubricant for driven systems
Plastic housings are available in conductive or non-conductive material with or without labyrinth seals
The labyrinth seal(s) provide protection to the bearing from dust, dirt, and airborne debris.
Stainless Steel/Plastic Housings
Designed for light to moderate loads, Stainless steel balls and raceways provide an excellent solution for corrosive operating environments For maximum protection against contamination, housing may be ordered with a double labyrinth seal ystem.Other housings are also available.
