High Speed ATC CNC Router (QL-M25-I)

Supply Ability:	150 Set/Sets per Month
Payment Terms:	L/C, T/T, Western Union

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	Plywood Case

Specifications

The models of excellence that the price of the High Accuracy ATC CNC Router models, with the M25 lies in the difference between the main tool change, three-axis machines Drive, Drive, etc., are the main components of the machines have to import high Client configuration, the double-track bilateral Taiwan-motivation, also a heavy cutting-processing models.

1, sub-keyboard control: simple, convenient and easy to learn the sub-keyboard operation, the user can quickly flexibility to use the equipment, More independence.

2, Taiwan's advanced CNC control systems, intelligent processing cross-border protection functions: to prevent the layout design of the processing rate of more than caused byMachinery collision phenomenon. Intelligent processing speed control: the processing speed can be controlled, truly improve processing efficiency, extended tool life, Improve the yield.

3, cleaning, adsorption devices: cleaning system in the course of processing wood and broken suction take Mo, to maintain the disguise of the table clean equipment
For the maintenance; absorption system to replace the previous mechanical plate fixed to improve the processing time for handling outside the plate.

4, the paper pretreated advanced features to help users promptly corrected the mistakes in processing documents, and to good-compatible domestic and foreign multi Kind of software (such as Mastercam, Typ3, UG, Artcam, Caxa, etc.) generated by the processing code. Advanced three-dimensional curves prediction algorithm, the presentation of A smooth line to ensure that the curve of speed and accuracy.

5, windows-based platform for the NC embedded systems, upgrading of unlimited expansion. Synchronization of anti-jamming software and hardware design, to ensure that System time reliable operation. A breakpoint, continued carving off function, back to square with automatic correction features, effectively guaranteed in a long time
The accuracy of processing work.

6 with two seamless steel structure used welding, rigid strong, not deformed.

NO. Description		Parameter
1	Table size	*16003100mm**
2	X,Y working area	*13002500mm**
3	Z working area	300mm
4	Processing precision	0.02mm
5	Reposition precision	0.05mm
6	Table structure	Vacuum table
7	X,Y,Z structure	Z ballscrew X,Y gearwheel
8	Self-consuming power	2.8KW
9	Max ilding speed	40000mm/min
10	Max working speed	25000mm/min
11	Spindle power	6.0KW
13	Working voltage	AC380V/50Hz
14	Spindle rotating speed	0-24000rpm/min
15	Drive Motor	Japan servo motor
16	Operation system	Taiwan LNC control system
17	Net weight	1000kg
18	Gross weight	1200kg
