688/720 Roll Forming Machine for Steel Structure Floor

Shipping:	FOB
Payment Terms:	L/C, T/T

Inquiry Now

Related products from verified members

High Quality Roll Forming Machine

Price:

Min. Order:1 Set
Metal Roof Ridge Capping Roll Forming Machine

Price:9580.00-12580.00 USD/Set

Min. Order:1 Set
Stud & Track Roll Forming Machine

Price:12500.00 USD/Set

Min. Order:1 Set

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China

Specifications

The unit is configured to manually open-book machines, forming the host, hydraulic cutter, electric control system, hydraulic system, and used for floor plate-type pressure.

Specifications

1. Automatic inner tensioning Decoiler

Max roll width: 550mm Maximum weight: 6000kg

Hydraulic power; 3kw Motor power; 3kw

Cylinder diameter: 120mm working pressure: 10Mpa

2. Forming the host

Rack row floor: 24 steps Main motor power: 22kw

Rolling speed: 9-12m/min

Roll thickness of hard chromium plated: 0.05mm

3. Hydraulic knife

Blade material: Cr12 Quenching

Cutting system: advanced hydraulic drive, feet cut off automatically after molding, no distortion, no waste, higher safety factor

Model	688
Effective coverage width(mm)	688
Expand width	1000
Thickness	0.8	1.0	1.2
Moment of inertia	91.62	119.38	142.01
Cross-section to resist moment	23.46	30.58	36.98

The unit model can also be produced according to user requirements.
